STOP LIGHT SWITCH
Measure the resistance between stop light switch terminals.
Scheme 65
- 5 door model
- 4 door model
Scheme 66
| Switch position | Terminal No. | Standard |
|---|---|---|
| When brake pedal is depressed | 5 door model: land 2 4 door model: 3 and 4 | Less than 1 ohms |
| When brake pedal is released | 1 Mohms or more |
RESISTANCE REFERENCE CHART
Replace the stop light switch if faulty.
Refer to "Interior Light System". Ref. to appropriate lighting wiring diagram in SYSTEM WIRING DIAGRAMS .
