Speed Control Systems (h4so Engine) Subaru Impreza WRX STI GD рестайлинг 2

SPECIFICATION

ACCELERATOR PEDAL SPECIFICATION CHART

Identifying Accelerator Pedal Components. Scheme 2

Tightening torque: N.m (kgf-m, ft-lb)

T: 18 (1.8, 13.0)

CAUTION

1. Wear work clothing, including a cap, protective goggles and protective shoes during operation.
2. Remove contamination including dirt and corrosion before removal, installation or disassembly.
3. Keep the disassembled parts in order and protect them from dust and dirt.
4. Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
5. Be careful not to burn yourself, because each part on the vehicle is hot after running.
6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
7. Place shop jacks or rigid racks at the specified points.
8. Before disconnecting electrical connectors of sensors or units, be sure to disconnect the ground cable from battery.

Scheme 3

1. Disconnect the ground cable from battery.
2. Disconnect the connector (A).
3. Remove the bolt (B) securing accelerator pedal assembly. (Scheme 3): Identifying Accelerator Pedal Assembly Bolt

INSTALLATION

Install in the reverse order of removal.

Tightening torque

18 N.m (1.8 kgf-m, 13.0 ft-lb)

DISASSEMBLY

Note. Accelerator pedal cannot be disassembled.
