WIRING DIAGRAM
Refer to "Headlight Beam Leveler System" in the wiring diagram. < Ref. to WIRING DIAGRAM , Headlight Beam Leveler System. >
Headlight beam leveler system < Ref. to WIRING DIAGRAM , Headlight Beam Leveler System. >
Scheme 96
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK OTHER COMMUNICATION. Communicate with the system other than the auto headlight beam leveler CM using the Subaru Select Monitor. | Is the communication to other control module possible? | Go to step 2 . | Perform the " COMMUNICATION FOR INITIALIZING IMPOSSIBLE " of LAN system. < Ref. to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , Subaru Select Monitor. > |
| 2 CHECK LAN SYSTEM. Inspect LAN system. < Ref. to PROCEDURE , Basic Diagnostic Procedure. > | Is there any fault? | Perform the inspection according to the diagnosis for LAN system. | Go to step 3 . |
| 3 CHECK FOR POOR CONTACT. Turn the ignition switch to OFF. Disconnect the auto headlight beam leveler CM connector. Connect the disconnected connectors. Communicate with the auto headlight beam leveler CM using the Subaru Select Monitor. | Is communication possible? | It is possible that temporary poor communication occurs. | Replace the auto headlight beam leveler CM. < Ref. to AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE . > |
Headlight beam leveler system < Ref. to WIRING DIAGRAM , Headlight Beam Leveler System. >
Scheme 97
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK DTC. Turn the ignition switch to OFF. Using the Subaru Select Monitor, clear the auto headlight beam leveler system memory. Turn the ignition switch to OFF --> ON. Use the Subaru Select Monitor and read DTCs. | Is DTC B2902 displayed? (current malfunction) | Go to step 2 . | System is normal. It is possible that temporary poor contact occurs. |
| 2 CHECK CURRENT DATA. Display {R Sensor Signal} using Subaru Select Monitor. | Does the data indicate the standard value? | Replace the auto headlight beam leveler CM. < Ref. to AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE . > | Go to step 3 . |
| 3 CHECK CURRENT DATA. Display {R Sensor Signal} using Subaru Select Monitor. Change the vehicle posture. | Does the data change? | Go to step 6 . | Go to step 4 . |
| 4 CHECK OUTPUT VOLTAGE BETWEEN AUTO HEADLIGHT BEAM LEVELER CM AND VEHICLE HEIGHT SENSOR. Disconnect the vehicle height sensor connector. Turn the ignition switch to ON. Measure the voltage between the vehicle height sensor connector and chassis ground. Connector & terminal (R29) No. 1 (+) - Chassis ground (-) | Is the voltage 5±0.25 V? | Go to step 5 . | Replace the auto headlight beam leveler CM. < Ref. to AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE . > |
| 5 CHECK REAR HEIGHT SENSOR. Remove the rear vehicle height sensor. Perform the inspection of rear height sensor unit. < Ref. to INSPECTION , Rear Height Sensor. > | Is the rear height sensor normal? | Go to step 6 . | Replace the rear height sensor. < Ref. to REAR HEIGHT SENSOR . > |
| 6 CHECK HARNESS. Disconnect the auto headlight beam leveler CM connector. Using a tester, measure the resistance between the auto headlight beam leveler CM connector and rear height sensor connector. Connector & terminal (B150) No. 12 - (R29) No. 1: (B150) No. 3 - (R29) No. 2: (B150) No. 19 - (R29) No. 3 | Is there continuity? | Go to step 7 . | Repair or replace the open circuit of harness. |
| 7 CHECK HARNESS. Using a tester, measure the resistance between the auto headlight beam leveler CM connector and chassis ground. Connector & terminal (B150) No. 3 - Chassis ground: (B150) No. 19 - Chassis ground: (B150) No. 12 - Chassis ground | Is the resistance 10 kohms or more? | Replace the auto headlight beam leveler CM. < Ref. to AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE . > | Repair or replace the short circuit of the harness. |
DTC PROCEDURE
Headlight beam leveler system < Ref. to WIRING DIAGRAM , Headlight Beam Leveler System. >
Scheme 98
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK CURRENT DATA. Display {ECU ACC} using Subaru Select Monitor. | Does the current data indicate the standard value? | Go to step 3 . | Go to step 2 . |
| 2 CHECK HARNESS BETWEEN POWER SUPPLY - AUTO HEADLIGHT BEAM LEVELER CM. Disconnect the auto headlight beam leveler CM connector. Turn the ignition switch to ON. Measure the voltage between the auto headlight beam leveler CM connector and chassis ground. Connector & terminal (B150) No. 1 (+) - Chassis ground (-) | Is the voltage 8 - 16 V? | Replace the auto headlight beam leveler CM. < Ref. to AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE . > | Repair or replace the harness. |
| 3 CHECK INDICATOR OUTPUT. Turn the ignition switch to ON. | Does the warning indicator turn on for three seconds? | Go to step 5 . | Go to step 4 . |
| 4 CHECK CURRENT DATA. Display {Indicator Signal} using Subaru Select Monitor. Turn the ignition switch to ON. | Is it set as ON for 3 seconds? | Go to step 6 . | Replace the auto headlight beam leveler CM. < Ref. to AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE . > |
| 5 CHECK INDICATOR OUTPUT. Leave the ignition switch to ON for 10 seconds. | Does the warning indicator light go off? | Go to step 9 . | Go to step 13 . |
| 6 CHECK HARNESS BETWEEN BATTERY - INDICATOR BULB - AUTO HEADLIGHT BEAM LEVELER CM. Disconnect the auto headlight beam leveler CM connector. Turn the ignition switch to ON. Measure the voltage between the auto headlight beam leveler CM (indicator bulb) connector and chassis ground. Connector & terminal (B150) No. 6 (+) - Chassis ground (-) | Is the voltage 12 V? | Replace the auto headlight beam leveler CM. < Ref. to AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE . > | Go to step 7 . |
| 7 CHECK INDICATOR BULB. Disconnect the combination meter connector. Measure the continuity between combination meter terminals. Connector & terminal (i10) No. 20 - (i10) No. 8 | Is there continuity? | Go to step 8 . | Replace the meter case assembly. < Ref. to COMBINATION METER . > |
| 8 CHECK HARNESS BETWEEN AUTO HEADLIGHT BEAM LEVELER CM AND INDICATOR BULB. Turn the ignition switch to OFF. Measure the continuity between the auto headlight beam leveler CM and the combination meter. Connector & terminal (B150) No. 6 - (i10) No. 8 | Is there continuity? | Replace the auto headlight beam leveler CM. < Ref. to AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE . > | Repair the open circuit and poor contact of the connector in the harness between the auto headlight beam leveler CM and indicator. |
| 9 CHECK HEADLIGHT ASSEMBLY (ACTUATOR) DRIVE. Connect the auto headlight beam leveler CM connector. Turn the ignition switch to ON, and within 10 seconds, repeat the OFF --> 2 (HEAD) operation of headlight switch 5 times. Check that the headlight beam drops once, then returns to normal. Then, after waiting for 30 seconds or more with the ignition ON, turn the ignition switch to OFF. | Does the headlight beam drop down once, and then return? | Replace the auto headlight beam leveler CM. < Ref. to AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE . > | Go to step 10 . |
| 10 CHECK HEADLIGHT ASSEMBLY (ACTUATOR) OUTPUT. Display {Actuator Signal} using Subaru Select Monitor. Turn the ignition switch to ON, and within 10 seconds, repeat the OFF --> 2 (HEAD) operation of headlight switch 5 times. Check that the headlight beam drops once, then returns to normal. Then, after waiting for 30 seconds or more with the ignition ON, turn the ignition switch to OFF. | Does the current data indicate the standard value? (Does the value change at 10 - 90%?) | Go to step 11 . | Replace the auto headlight beam leveler CM. < Ref. to AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE . > |
| 11 CHECK OUTPUT VOLTAGE BETWEEN HEADLIGHT ASSEMBLY (ACTUATOR). Disconnect the auto headlight beam leveler CM connector. Turn the ignition switch to ON. Measure the voltage between the auto headlight beam leveler CM connector and chassis ground. Connector & terminal (B150) No. 10 (+) - Chassis ground (-) | Is the voltage 12 V? | Replace the headlight assembly. < Ref. to HEADLIGHT ASSEMBLY . > | Go to step 12 . |
| 12 CHECK HARNESS BETWEEN AUTO HEADLIGHT BEAM LEVELER CM AND HEADLIGHT ASSEMBLY (ACTUATOR). Disconnect the connector of headlight assembly. Measure the continuity between the auto headlight beam leveler CM connector and headlight assembly (actuator) connector. Connector & terminal Headlight beam leveler RH (B150) No. 10 - (F126) No. 6: (B150) No. 17 - (F126) No. 8: (B150) No. 11 - (F126) No. 7: Headlight beam leveler LH (B150) No. 10 - (F125) No. 6: (B150) No. 17 - (F125) No. 8: (B150) No. 11 - (F125) No. 7 | Is there continuity? | Replace the auto headlight beam leveler CM. < Ref. to AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE . > | Repair the open circuit or poor contact of the connector in the harness between headlight assembly and auto headlight beam leveler CM. |
| 13 CHECK DTC. Display DTC using the Subaru Select Monitor. | Is DTC displayed? | Perform the diagnosis according to DTC. < Ref. to LIST , List of Diagnostic Trouble Code (DTC). > | Replace the auto headlight beam leveler CM. < Ref. to AUTO HEADLIGHT BEAM LEVELER CONTROL MODULE . > |
