Exhaust System (H4DOTC): Overview Subaru Forester SJ

Exhaust 3 illustrations ~106 words

Scheme 18: FRONT EXHAUST PIPE

Tightening torque: N.m (kgf-m, ft-lb)

T1: 6.4 (0.7, 4.7)

T2: 13 (1.3, 9.6)

T3: 19 (1.9, 14.0)

T4: 30 (3.1, 22.1)

T5: 33 (3.4, 24.3)

T6: 42.5 (4.3, 31.3)

Scheme 19: CENTER AND REAR EXHAUST PIPE, AND MUFFLER

Tightening torque: N.m (kgf-m, ft-lb)

T1: 7.5 (0.8, 5.5)

T2: 13 (1.3, 9.6)

T3: 18 (1.8, 13.3)

T4: 23 (2.3, 17.0)

T5: 35 (3.6, 25.8)

T6: 42.5 (4.3, 31.3)

T7: 48 (4.9, 35.4)

T8: < Ref. to INSTALLATION , Front Oxygen (A/F) Sensor. >

T9: < Ref. to INSTALLATION , Rear Oxygen Sensor. >

Scheme 20: HEAT SHIELD COVER

Tightening torque: N.m (kgf-m, ft-lb)

T1: 10 (1.0, 7.4)

T2: 18 (1.8, 13.3)
