WIRING DIAGRAM
< Ref. to WIRING DIAGRAM , Cruise Control System. >
Cruise control system < Ref. to WIRING DIAGRAM , Cruise Control System. >
Scheme 6
Scheme 7
- Non-turbo model
- Turbo model
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK CRUISE CONTROL COMMAND SWITCH CIRCUIT. Remove the driver's airbag module. < Ref. to REMOVAL , Driver's Airbag Module. > Disconnect the harness connector of cruise control command switch. Turn the ignition switch to ON. Measure the voltage between harness connector terminal and chassis ground. Connector & terminal (ST3) No. 4 (+) - Chassis ground (-): (ST3) No. 3 (+) - Chassis ground (-) | Is the voltage 5 V or more? | Go to step 2 . | Check the harness between cruise control command switch and ECM, and the steering roll connector for open or short circuit, or for poor contact. |
| 2 CHECK CRUISE CONTROL COMMAND SWITCH CIRCUIT. Turn the ignition switch to OFF. Remove the cruise control command switch. < Ref. to REMOVAL , Cruise Control Command Switch. > Measure the resistance between harness connector terminal and chassis ground. Connector & terminal (ST3) No. 9 - Chassis ground | Is the resistance less than 10 ohms? | Go to step 3 . | Check for open circuit between cruise control command switch, ECM, and chassis ground and check the ECM. |
| 3 CHECK CRUISE CONTROL COMMAND SWITCH. Measure the resistance between switch terminals when the cruise control command switch is not depressed. Terminals No. 3 - No. 9 | Is the resistance approx. 4 kohms? | Go to step 4 . | Replace the cruise control command switch. < Ref. to CRUISE CONTROL COMMAND SWITCH . > |
| 4 CHECK CANCEL SWITCH. Turn the ignition switch to OFF. Remove the cruise control command switch. < Ref. to REMOVAL , Cruise Control Command Switch. > Measure the resistance between switch terminals with the CANCEL switch pressed. Terminals No. 3 - No. 9 | Is the resistance approx. less than 1 ohms when the CANCEL switch is pressed? | Go to step 5 . | Replace the cruise control command switch. < Ref. to CRUISE CONTROL COMMAND SWITCH . > |
| 5 CHECK SET/-- SWITCH. Measure the resistance between the switch terminals with the SET/-- switch pressed. Terminals No. 3 - No. 9 | Is the resistance approx. 250 ohms when the SET/-- switch is pressed? | Go to step 6 . | Replace the cruise control command switch. < Ref. to CRUISE CONTROL COMMAND SWITCH . > |
| 6 CHECK RES/+ SWITCH. Measure the resistance between the switch terminals with the RES/+ switch pressed. Terminals No. 3 - No. 9 | Is the resistance approx. 1, 500 ohms when the RES/+ switch is pressed? | Replace the ECM. < Ref. to ENGINE CONTROL MODULE (ECM) . > | Replace the cruise control command switch. < Ref. to CRUISE CONTROL COMMAND SWITCH . > |
Cruise control system < Ref. to WIRING DIAGRAM , Cruise Control System. >
Scheme 8
Scheme 9
- Non-turbo model
- Turbo model
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK STOP LIGHT & BRAKE SWITCH. Check the stop light & brake switch. < Ref. to STOP LIGHT & BRAKE SWITCH . > | Is the stop light & brake switch and installation position OK? | Go to step 2 . | Replace the stop light & brake switch. Or adjust the installation position. |
| 2 CHECK STOP LIGHT & BRAKE SWITCH CIRCUIT. Turn the ignition switch to OFF. Disconnect the stop light & brake switch harness connector. Turn the ignition switch to ON. Measure the voltage between harness connector terminal and chassis ground. Connector & terminal (B65) No. 3 (+) - Chassis ground (-) | Is the voltage 10 V or more? | Go to step 3 . | Check fuse No. 8 (in fuse & relay box). Check for open or short in the harness between stop light & brake switch and fuse & relay box. |
| 3 CHECK STOP LIGHT & BRAKE SWITCH CIRCUIT. Measure the voltage between harness connector terminal and chassis ground. Connector & terminal (B65) No. 1 (+) - Chassis ground (-) | Is the voltage 10 V or more? | Go to step 4 . | Check fuse No. 4 (in fuse & relay box). Check for open or short in the harness between stop light & brake switch and fuse & relay box. |
| 4 CHECK STOP LIGHT & BRAKE SWITCH CIRCUIT. Turn the ignition switch to OFF. Disconnect the harness connector of ECM. Measure the resistance between ECM harness connector terminal and stop light & brake switch harness connector terminal. Connector & terminal Non-turbo model (B137) No. 3 - (B65) No. 4: (B137) No. 7 - (B65) No. 2: Turbo model (E158) No. 8 - (B65) No. 4: (B134) No. 43 - (B65) No. 2 | Is the resistance less than 10 ohms? | Replace the ECM. < Ref. to ENGINE CONTROL MODULE (ECM) . > | Repair the harness. |
Cruise control system < Ref. to WIRING DIAGRAM , Cruise Control System. >
Scheme 10
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK CLUTCH SWITCH. Check the clutch switch. < Ref. to CLUTCH SWITCH . > | Is the clutch switch and installation position OK? | Go to step 2 . | Replace the clutch switch. Or adjust the installation position. |
| 2 CHECK CLUTCH SWITCH CIRCUIT. Turn the ignition switch to OFF. Disconnect the clutch switch harness connector. Turn the ignition switch to ON. Measure the voltage between harness connector terminal and chassis ground. Connector & terminal (B107) No. 1 (+) - Chassis ground (-) | Is the voltage 10 V or more? | Go to step 3 . | Check fuse No. 4 (in fuse & relay box). Check open or shorted circuit of harness between clutch switch and fuse & relay box. |
| 3 CHECK CLUTCH SWITCH CIRCUIT. Turn the ignition switch to OFF. Disconnect the harness connector of ECM. Measure the resistance between clutch switch harness connector terminal and ECM harness connector terminal. Connector & terminal (B107) No. 2 - (B137) No. 15 | Is the resistance less than 10 ohms? | Replace the ECM. < Ref. to ENGINE CONTROL MODULE (ECM) . > | Repair the harness. |
Cruise control system < Ref. to WIRING DIAGRAM , Cruise Control System. >
Scheme 11
Scheme 12
- Non-turbo model
- Turbo model
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK TRANSMISSION TYPE. | Is the transmission type CVT? | Go to step 2 . | Go to step 5 . (MT model) |
| 2 CHECK INHIBITOR SWITCH CIRCUIT. Turn the ignition switch to OFF. Disconnect the inhibitor switch harness connector. Turn the ignition switch to ON. Measure the voltage between harness connector terminal and chassis ground. Connector & terminal (T7) No. 6 (+) - Chassis ground (-) | Is the voltage 10 V or more? | Go to step 3 . | Check for open or short in the harness between inhibitor switch and ECM. |
| 3 CHECK INHIBITOR SWITCH CIRCUIT. Turn the ignition switch to OFF. Disconnect the starter motor harness connector. Measure the resistance between inhibitor switch harness connector terminal and starter motor. Connector & terminal (T7) No. 9 - Starter motor | Is the resistance less than 10 ohms? | Go to step 4 . | Repair the harness. |
| 4 CHECK INHIBITOR SWITCH. Remove and check the inhibitor switch. < Ref. to INHIBITOR SWITCH . > | Is the inhibitor switch working normal? | Replace the ECM. < Ref. to ENGINE CONTROL MODULE (ECM) . > | Replace the inhibitor switch. |
| 5 CHECK NEUTRAL POSITION SWITCH CIRCUIT. Turn the ignition switch to OFF. Disconnect the neutral position switch harness connector. Turn the ignition switch to ON. Measure the voltage between harness connector terminal and chassis ground. Connector & terminal (B25) No. 2 (+) - Chassis ground (-) | Is the voltage 10 V or more? | Go to step 6 . | Check for open or short in the harness between neutral position switch and ECM. |
| 6 CHECK NEUTRAL POSITION SWITCH CIRCUIT. Turn the ignition switch to OFF. Measure resistance between harness connector terminal of neutral position switch and chassis ground. Connector & terminal (B25) No. 1 - Chassis ground | Is the resistance less than 10 ohms? | Go to step 7 . | Repair the harness. |
| 7 CHECK NEUTRAL POSITION SWITCH. Remove and check the neutral position switch. < Ref. to NEUTRAL POSITION SWITCH . > | Is the neutral position switch OK? | Replace the ECM. < Ref. to ENGINE CONTROL MODULE (ECM) . > | Replace the neutral position switch. |
Cruise control system < Ref. to WIRING DIAGRAM , Cruise Control System. >
Scheme 13
Scheme 14
- Non-turbo model
- Turbo model
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK IGNITION SWITCH CIRCUIT. Turn the ignition switch to OFF. Disconnect the ECM harness connector. Turn the ignition switch to ON. Measure the voltage between harness connector terminal and chassis ground. Connector & terminal Non-turbo model (B137) No. 27 (+) - Chassis ground (-): Turbo model (B134) No. 32 (+) - Chassis ground (-) | Is the voltage 10 V or more? | Check for poor contact of ECM connector. | Check fuse No. 12 (in fuse & relay box). Check the harness for open or short circuit between ignition switch and ECM. |
