SPECIFICATION
| Front disc brake | Size | 16-inch type | 17-inch type | |
|---|---|---|---|---|
| Type | Disc (floating type, ventilated) | |||
| Effective disc diameter | Mm (in) | 244 (9.61) | 261 (10.28) | |
| Disc thickness x Diameter | Mm (in) | 24 x 294 (0.94 x 11.57) | 30 x 316 (1.18 x 12.44) | |
| Effective cylinder diameter | Mm (in) | 42.8 (1.685) x 2 | ||
| Pad dimensions (Length x Width x Thickness) | Mm (in) | 117.8 x 50.5 x 11.0 (4.638 x 1.988 x 0.433) | 130.0 x 53.5 x 11.0 (5.118 x 2.106 x 0.433) | |
| Clearance adjustment | Automatic adjustment | |||
| Rear disc brake | Size | 15-inch type | 16-inch type | |
| Type | Disc (floating type, solid) | Disc (floating type, ventilated) | ||
| Effective disc diameter | Mm (in) | 238 (9.37) | 243 (9.57) | |
| Disc thickness x Diameter | Mm (in) | 10 x 274 (0.39 x 10.79) | 18 x 278 (0.71 x 10.94) | |
| Effective cylinder diameter | Mm (in) | 38.1 (1.500) | 40.4 (1.591) | |
| Pad dimensions (Length x Width x Thickness) | Mm (in) | 92.0 x 33.0 x 9.0 (3.622 x 1.299 x 0.354) | 95.5 x 34.8 x 11.0 (3.759 x 1.370 x 0.433) | |
| Clearance adjustment | Automatic adjustment | |||
| Master cylinder | Type | Tandem | ||
| Effective diameter | Mm (in) | 23.8 (15/16) | ||
| Reservoir type | Sealed type | |||
| Brake fluid reservoir capacity | Cm 3 (cu in) | 240 (12.51) | ||
| Brake booster | Type | Vacuum suspended | ||
| Effective diameter | Mm (in) | 208 + 229 (8.19 + 9.02) | ||
| Brake line | Dual circuit system | |||
| Brake fluid | FMVSS No. 116, DOT3 or DOT4 CAUTION: Avoid mixing brake fluid of different brands to prevent fluid performance from degrading. When filling with brake fluid, be careful not to allow any dust to enter the reservoir. Use new SUBARU genuine brake fluid when replacing or refilling the fluid. | |||
| CAUTION |
|---|
| Avoid mixing brake fluid of different brands to prevent fluid performance from degrading. When filling with brake fluid, be careful not to allow any dust to enter the reservoir. Use new SUBARU genuine brake fluid when replacing or refilling the fluid. |
Note. Refer to "PARKING BRAKE" for parking brake specifications. < Ref. to SPECIFICATION , General Description. >
| Item | Standard | Limit | ||
|---|---|---|---|---|
| Front brake | Pad thickness mm (in) | All models | 11 (0.43) | 1.5 (0.059) |
| Disc thickness mm (in) | 16-inch | 24 (0.94) | 22 (0.87) | |
| 17-inch | 30 (1.18) | 28 (1.10) | ||
| Disc runout mm (in) | All models | 0.05 (0.0020) | ||
| Rear brake (disc type) | Pad thickness mm (in) | Solid disc | 9.0 (0.354) | 1.5 (0.059) |
| Pad thickness mm (in) | Ventilated disc | 11 (0.43) | 1.5 (0.059) | |
| Disc thickness mm (in) | Solid disc | 10 (0.39) | 8.5 (0.335) | |
| Disc thickness mm (in) | Ventilated disc | 18 (0.71) | 16 (0.63) | |
| Disc runout mm (in) | 0.05 (0.0020) | |||
| Parking brake | Inside diameter mm (in) | 170 (6.69) | 171 (6.73) | |
| Lining thickness mm (in) | 3.5 (0.14) | 1.5 (0.059) | ||
| Brake pedal force N (kgf, lbf) | Fluid pressure kPa (kgf/cm 2 , psi) | ||
|---|---|---|---|
| Brake booster | Brake fluid pressure with engine stopped | 147 (15, 33) | 553 (5, 77) |
| 294 (30, 66) | 1, 551 (16, 225) | ||
| Brake fluid pressure with engine running and vacuum pressure at 66.7 kPa (500 mmHg, 19.69 inHg) | 147 (15, 33) | 6, 177 (63, 896) | |
| 294 (30, 66) | 11, 273 (115, 1, 635) | ||
| Brake pedal | Free play | Mm (in) | 0.5 - 2 (0.020 - 0.079) [When pulling the brake pedal upward with a force of less than 10 N (1 kgf, 2 lbf)] |
Scheme 44
Tightening torque: N.m (kgf-m, ft-lb)
T1: 8 (0.82, 5.9)
T2: 27 (2.75, 19.9)
T3: 80 (8.16, 59.0)
Scheme 45
Tightening torque: N.m (kgf-m, ft-lb)
T1: 8 (0.82, 5.9)
T2: 27 (2.75, 19.9)
T3: 66 (6.73, 48.7)
Scheme 46
Tightening torque: N.m (kgf-m, ft-lb)
T: 13 (1.33, 9.6)
Scheme 47
Scheme 48
- Models without EyeSight Tightening torque: N.m (kgf-m, ft-lb) T1: 15 (1.53, 11.1) T2: 18 (1.84, 13.3) T3: 19 (1.94, 14.0) T4: 33 (3.36, 24.3)
- Models with EyeSight Tightening torque: N.m (kgf-m, ft-lb) T1: 7.5 (0.76, 5.5) T2: 15 (1.53, 11.1) T3: 18 (1.84, 13.3) T4: 19 (1.94, 14.0) T5: 33 (3.36, 24.3)
Scheme 49
Tightening torque: N.m (kgf-m, ft-lb)
T1: 15 (1.53, 11.1)
T2: 18 (1.84, 13.3)
T3: 33 (3.36, 24.3)
Scheme 50
Tightening torque: N.m (kgf-m, ft-lb)
T: 18 (1.84, 13.3)
Scheme 51
Scheme 52
- CVT model Tightening torque: N.m (kgf-m, ft-lb) T1: 18 (1.84, 13.3) T2: 30 (3.06, 22.1)
- MT model Tightening torque: N.m (kgf-m, ft-lb) T1: 8 (0.82, 5.9) T2: 18 (1.84, 13.3)
Scheme 53
Tightening torque: N.m (kgf-m, ft-lb)
T1: 7.5 (0.76, 5.5)
T2: 19 (1.9, 14.0)
