CAUTION
- Before disassembling or reassembling parts, always disconnect the battery ground cable from battery. When replacing the audio, control module and other parts provided with memory functions, record the memory contents before disconnecting the battery ground cable. Otherwise, the memory is cleared.
- Reassemble the parts in the reverse order of disassembly procedure unless otherwise indicated.
- Connect the connectors securely during reassembly.
- After reassembly, make sure that the each component operates normally.
- Yellow connectors and harnesses with yellow tapes around them are the connectors and harnesses for the airbag system. Using a tester above such circuits may cause malfunction of airbag system. Follow the cautions of "AIRBAG SYSTEM" in this case. < Ref. to «CAUTION»(ref-662142-S33828179652014101300000) , General Description. >
- Be careful not to damage the airbag system wiring harness when servicing electrical parts and switches.
GENERAL TOOL
| TOOL NAME | REMARKS |
|---|---|
| Circuit tester | Used for measuring resistance and voltage. |
Scheme 12
| Main fuse box | Fuse 15 A (horn assembly - Hi, Lo) | (A) |
|---|---|---|
| Horn relay | (B) |
Note. For other related fuses, refer to the wiring diagram. < Ref. to POWER SUPPLY CIRCUIT . >
CHECK FUSE
- Remove the fuse and check visually.
- If the fuse is blown out, replace the fuse.
Scheme 13
- Check the resistance between relay terminals. Terminal No. Inspection conditions Specification Circuit 1 - 2 Always 1 Mohms or more 1 - 2 Apply battery voltage between 4 - 3 terminals. Less than 1 ohms
- Replace the relay if the inspection result is not within the standard value.
NOTE
For operation procedures of each component of the horn system, refer to the respective section.
- Horn ASSY: < Ref. to «HORN»(ref-662183-S08799954882014101300000) . >
- Horn switch: < Ref. to «HORN SWITCH»(ref-662183-S41463451922014101300000) . >
