NOTE Subaru Forester SJ

Exterior/interior Trim 14 illustrations ~619 words

NOTE

Refer to "FUEL INJECTION" section for removal and installation procedure of the fuel tank protector. < Ref. to FUEL TANK PROTECTOR . >

Scheme 130

Scheme 130: FRONT GRILLE UPPER
Scheme 130: FRONT GRILLE UPPER

Scheme 131

Scheme 131
Scheme 131

Scheme 132

Scheme 132
Scheme 132
  1. Remove the nuts, and remove the bracket - grille UPR.
  2. Remove the nuts, and remove the grille assembly - front CTR.
  3. Remove the nuts, and remove the grille assembly - front UPR.

Scheme 133

Scheme 133: FRONT GRILLE LOWER
Scheme 133: FRONT GRILLE LOWER

Scheme 134

Scheme 134
Scheme 134

Scheme 135

Scheme 135
Scheme 135

Scheme 136

Scheme 136
Scheme 136
  1. Remove the bumper face - front. Remove the screws and clips, and turn over the mud guard - front, and then disconnect the connectors of the fog light assembly - front on the LH and RH sides. (Model with fog light) Remove the clips at the upper side of the bumper face - front. Remove the clips from the fender. Remove the clips at the lower side of the bumper face - front. Apply protective tape (A) to the light assembly - head. Release the clips, and while pushing up the lower side (a) of the bumper face - front, remove in the order from (b) to (e). CAUTION: Do not pull forcibly. It may damage the flange sections of the bumper face - front. NOTE: Detach the opposite side in the same manner.
  2. Remove the front grille assembly. Remove the screws from the back side of the bumper face - front. Release the claws, and remove the grille assembly - front LWR.

Refer to the " FRONT HOOD " section of "EXTERIOR BODY PANELS" for removal and installation procedure of the front hood duct. < Ref. to FRONT HOOD INSULATOR , REMOVAL, Front Hood. >

Scheme 137

Scheme 137
Scheme 137

Scheme 138

Scheme 138
Scheme 138

Scheme 139

Scheme 139
Scheme 139

Scheme 140

Scheme 140
Scheme 140

Scheme 141

Scheme 141
Scheme 141

Scheme 142

Scheme 142
Scheme 142

Scheme 143

Scheme 143
Scheme 143
  1. Disconnect the ground cable from battery.
  2. Remove the bumper face - front. Remove the screw and clips, and turn over the mud guard - front. Disconnect the connector of the left and right fog light assembly - front or the light assembly - daytime running. (If equipped) Remove the clips at the upper side of the bumper face - front. Remove the clips from the fender. Remove the clips at the lower side of the bumper face - front. Apply protective tape (A) to the light assembly - head. Release the clips, and while pushing up the lower side (a) of the bumper face - front, remove in the order from (b) to (e). CAUTION: Do not pull forcibly. It may damage the flange sections of the bumper face - front. NOTE: Detach the opposite side in the same manner.
  3. Remove the bumper beam COMPL - front. Remove the energy absorber - front bumper. Remove the bolts, and remove the bumper beam COMPL - front.
  4. Remove the clip, and remove the bracket - grille. NOTE: The bracket - grille can be removed without removing the bumper face - front by referring to the removal procedure in "Condenser" of "HVAC SYSTEM". < Ref. to «REMOVAL»(ref-662134-S14804673642014101300000) , Condenser. >
  5. Remove the bracket - front bumper. Removal of the bracket - front bumper corner Remove the bolts and clips, and remove the bracket - front bumper corner. Removal of the bracket - front bumper side Remove the bolts and clips, and remove the headlight assembly and the bracket - front bumper corner. Remove the screws. Remove the claws from behind the fender COMPL - front, and remove the bracket - front bumper side.
  6. Remove the bracket - front bumper side. Remove the bolts and clips, and remove the headlight assembly and the bracket - front bumper corner. Remove the screws. Remove the claws from behind the fender COMPL - front, and remove the bracket - front bumper side.
  7. Remove the bolt and pin, and remove the fog light assembly - front.
