WIRING DIAGRAM
Refer to "Navigation System" in the wiring diagram. < Ref. to WIRING DIAGRAM , Navigation System. >
Refer to "Rearview Camera System" in the wiring diagram. < Ref. to WIRING DIAGRAM , Rearview Camera System. >
Scheme 27
- Disconnect the ground cable from battery.
- Remove the trim panel - rear gate and the garnish assembly - rear gate. < Ref. to «REMOVAL»(ref-662136-S38233867252014101300000) , Rear Gate Garnish. >
- Remove the rearview camera assembly. CAUTION: Do not drop or apply any impact to the rearview camera because it is a precision equipment. Disconnect the rearview camera connector. Disconnect the claws and then remove the rearview camera assembly.
Refer to "Front Accessory Power Supply Socket System" in the wiring diagram. < Ref. to WIRING DIAGRAM , Front Accessory Power Supply Socket System. >
Scheme 28
- Disconnect the ground cable from battery.
- Remove the front accessory power supply socket. Disconnect the connector. While releasing the claw inside the accessory power supply socket, press in the claw from the rear to remove the accessory power supply socket. NOTE: If it is hard to remove, remove the panel center assembly and then release the claws from behind.
Refer to "Rear Accessory Power Supply Socket System" in the wiring diagram. < Ref. to WIRING DIAGRAM , Rear Accessory Power Supply Socket System. >
Scheme 29
- Disconnect the ground cable from battery.
- Open the console box, and remove the rear accessory power supply socket. While releasing the claw inside the accessory power supply socket, pull it toward you to remove the accessory power supply socket. Disconnect the connector, and remove the accessory power supply socket and holder. NOTE: If it is hard to remove, remove the console box assembly and then release the claws from behind.
