Differentials: Removal & Installation Subaru Forester SJ

REPLACEMENT

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Lift up the vehicle.
2. Remove the drain plug and filler plug, and drain the gear oil. T-type VA1-type
3. Tighten the drain plug. NOTE: For the T-type, apply liquid gasket to the drain plug. Liquid gasket: THREE BOND 1105 (Part No. 004403010) or equivalent For VA type, use a new gasket. Tightening torque: T-type 49 N.m (5.0 kgf-m, 36.1 ft-lb) VA-type: 50 N.m (5.1 kgf-m, 36.9 ft-lb)
4. Fill the differential carrier with gear oil to the bottom of filler plug. NOTE: Carefully refill gear oil while watching the level. Excessive or insufficient oil must be avoided. Recommended gear oil: < Ref. to «SPECIFICATION»(ref-662127-S25578793192014101300000) , General Description. > Oil capacity: 0.8 L (0.8 US qt, 0.7 Imp qt) T-type VA1-type
5. Install the filler plug. NOTE: For the T-type, apply liquid gasket to the filler plug. Liquid gasket: THREE BOND 1105 (Part No. 004403010) or equivalent For VA type, use a new gasket. Tightening torque: T-type: 49 N.m (5.0 kgf-m, 36.1 ft-lb) VA-type: 50 N.m (5.1 kgf-m, 36.9 ft-lb)

REMOVAL

The removal procedure for VA-type is included in "REMOVAL" for T-type. < Ref. to REMOVAL , Rear Differential (T-type). >

INSTALLATION

The installation procedure for VA-type is included in "INSTALLATION" for T-type. < Ref. to INSTALLATION , Rear Differential (T-type). >

1. Install the rear differential front member, and temporarily attach and tighten a new self-locking nut.
2. Remove the transmission jack.
3. Tighten the self-locking nut. Tightening torque: T1: 50 N.m (5.1 kgf-m, 36.9 ft-lb) T2: 110 N.m (11.2 kgf-m, 81.1 ft-lb)

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

1. Remove the rear differential. < Ref. to «REMOVAL»(ref-662127-S36563148422014101300000) , Rear Differential (T-type). > < Ref. to «REMOVAL»(ref-662127-S39799607872014101300000) , Rear Differential (VA-type). >
2. Fit the ST to the periphery of the sub frame cylinder, and make sure that the ST does not contact with welded spots or spatters. ST 41399FG010 SPECIAL TOOL A
3. If the ST contacts with welded spots or spatters, remove the excessive welds or spatters with sander or the equivalent so that the ST contacts the cylinder peripheral part. CAUTION: Performing the operation with the ST contacting with welded spots or spatters may break the ST. Be sure to remove excessive welds or spatters before the operation.
4. Set ST1, ST2, ST3, ST4 and ST5 as shown in the figure. ST1 41399FG091 SPECIAL TOOL SHAFT ST2 41399FG070 SPECIAL TOOL NUT ST3 41399FG050 SPECIAL TOOL SLEEVE ST4 41399FG080 SPECIAL TOOL BEARING ST5 41399FG010 SPECIAL TOOL A
5. Fit and hold the ST1 and ST2 to the rear differential mount bushing from the rear side of vehicle. ST1 41399FG031 SPECIAL TOOL C ST2 41399FG061 SPECIAL TOOL RING
6. Insert the ST set in the step 4 ) through the rear differential mount bushing hole from the front side of vehicle, and screw in the ST1 by hand till the front end of ST1 comes out slightly from the rear end of ST2. ST1 41399FG091 SPECIAL TOOL SHAFT ST2 41399FG061 SPECIAL TOOL RING
7. Hold the ST1 to prevent it from rotating, and screw in the ST3 by hand till there is no loose fit on the ST2. CAUTION: When setting the ST to the vehicle, always make sure that the ST2 fits the periphery of the sub frame cylinder and is not tilted. ST1 41399FG091 SPECIAL TOOL SHAFT ST2 41399FG010 SPECIAL TOOL A ST3 41399FG070 SPECIAL TOOL NUT
8. Hold the ST1 with a tool to prevent it from rotating, and screw in the ST2 to remove the rear differential mount bushing. CAUTION: Rotation of ST1 will damage the screw at the rear end of rear differential mount bushing. Never rotate the ST1. If the ST starts to tilt while removing the rear differential mount bushing, stop the work and set the ST again. ST1 41399FG091 SPECIAL TOOL SHAFT ST2 41399FG070 SPECIAL TOOL NUT
9. Set ST1, ST2, ST3, ST4, ST5 and rear differential mount bushing as shown in the figure. NOTE: Set the ST2 nut near to the end of ST1 screw. Hold the rear differential mount bushing with the marked side facing toward the rear of the vehicle, and set the rear differential mount bushing to the ST so that the arrow mark faces upward. Mark the bottom end of rear differential mount bushing to identify the installing direction. ST1 41399FG091 SPECIAL TOOL SHAFT ST2 41399FG070 SPECIAL TOOL NUT ST3 41399FG050 SPECIAL TOOL SLEEVE ST4 41399FG080 SPECIAL TOOL BEARING ST5 41399FG020 SPECIAL TOOL B
10. Attach ST1 to the ST2, and fit and hold the STs as a unit to the sub frame from the rear side of vehicle. ST1 41399FG061 SPECIAL TOOL RING ST2 41399FG041 SPECIAL TOOL D
11. Insert the ST and rear differential mount bushing set in the step 9 ) through the sub frame from the front side of vehicle, and screw in the ST1 by hand till the front end of ST1 comes out slightly from the rear end of ST2. CAUTION: Set the rear differential mount bushing with its mark facing the bottom end direction. ST1 41399FG091 SPECIAL TOOL SHAFT ST2 41399FG061 SPECIAL TOOL RING
12. Hold the ST1 to prevent it from rotating, and screw in the ST2 by hand till there is no loose fit on the ST and the rear differential mount bushing. CAUTION: Make sure that the ST and rear differential mount bushing are not tilted. ST1 41399FG091 SPECIAL TOOL SHAFT ST2 41399FG070 SPECIAL TOOL NUT
13. Screw in the ST2 while holding the ST1 with a tool to prevent it from rotating, and press-fit the rear differential mount bushing to the front end of sub frame cylinder. ST1 41399FG091 SPECIAL TOOL SHAFT ST2 41399FG070 SPECIAL TOOL NUT
14. Make sure that the rear differential mount bushing is inserted to the front end of sub frame cylinder.
15. Install the rear differential. < Ref. to «INSTALLATION»(ref-662127-S26050899442014101300000) , Rear Differential (T-type). > < Ref. to «INSTALLATION»(ref-662127-S19383524212014101300000) , Rear Differential (VA-type). >
