SPECIFICATION
| Item | Specifications | ||||
|---|---|---|---|---|---|
| Vehicle model | Non-turbo model | Turbo model | |||
| CVT | MT | ||||
| Starter | Type | Reduction type | |||
| Model | M000T38571 | M000T33176 | M000T20176 | ||
| Manufacturer | Mitsubishi Electric | ||||
| Voltage and output | 12 V - 1.2 kW | 12 V - 1.0 kW | 12 V - 1.4 kW | ||
| Direction of rotation | Counterclockwise (when observed from pinion) | ||||
| Number of pinion teeth | 9 | 8 | 9 | ||
| No-load characteristics | Voltage | 11 V | |||
| Current | 90 A or less | 95 A or less | 90 A or less | ||
| Rotating speed | 2, 370 rpm or more | 2, 500 rpm or more | 2, 000 rpm or more | ||
| Load characteristics | Voltage | 7.5 V | 7.5 V | 7.7 V | |
| Current | 300 A | 300 A | 400 A | ||
| Torque | 10.65 N.m (1.1 kgf-m, 7.8 ft-lb) or more | 8.84 N.m (0.9 kgf-m, 6.5 ft-lb) or more | 16.7 N.m (1.7 kgf-m, 12.3 ft-lb) or more | ||
| Rotating speed | 840 rpm or more | 870 rpm or more | 710 rpm or more | ||
| Lock characteristics | Voltage | 4 V | 4 V | 3.5 V | |
| Current | 780 A or less | 680 A or less | 960 A or less | ||
| Torque | 20 N.m (2.0 kgf-m, 14.8 ft-lb) or more | 17 N.m (1.7 kgf-m, 12.5 ft-lb) or more | 31 N.m (3.2 kgf-m, 22.9 ft-lb) or more | ||
| Generator | Type | Rotating-field three-phase type, voltage regulator built-in type, with load response control system | |||
| Model | A2TX3381 | ||||
| Manufacturer | Mitsubishi Electric | ||||
| Voltage and output | 12 V - 130 A | ||||
| Polarity on ground side | Negative | ||||
| Direction of rotation | Clockwise (when observed from pulley side) | ||||
| Stator connection | 3-phase delta type | ||||
| Output current | 1, 500 rpm - 50 A or more 2, 500 rpm - 111 A or more 5, 000 rpm - 133 A or more | ||||
| Regulated voltage | 14.1 - 14.8 V [20°C (68°F)] | ||||
| Rotor slip ring outer diameter | Standard | 22.7 mm (0.894 in) | |||
| Limit | 22.1 mm (0.870 in) | ||||
| Brush length | Standard | 22.5 mm (0.886 in) | |||
| Limit | 5.0 mm (0.197 in) | ||||
| Battery | Type and capacity | 12 V - 48 AH (55D 23L) | |||
Scheme 3
Tightening torque: N.m (kgf-m, ft-lb)
T1: 1.4 (0.1, 1.0)
T2: 6 (0.6, 4.4)
T3: 7.5 (0.8, 5.5)
T4: 10 (1.0, 7.4)
Scheme 4
Tightening torque: N.m (kgf-m, ft-lb)
T1: 2 (0.2, 1.5)
T2: 3.9 (0.4, 2.9)
T3: 4.4 (0.4, 3.2)
T4: 8.9 (0.9, 6.6)
T5: 108 (11.0, 79.8)
Scheme 5
Tightening torque: N.m (kgf-m, ft-lb)
T1: 6.4 (0.7, 4.7)
T2: 16 (1.6, 11.8)
T3: 25 (2.5, 18.4)
T4: 36 (3.7, 26.6)
T5: < Ref. to INSTALLATION , Generator. >
Scheme 6
Tightening torque: N.m (kgf-m, ft-lb)
T1: 7.5 (0.8, 5.5)
T2: 9 (0.9, 6.6)
T3: 14 (1.4, 10.3)
