PROPELLER SHAFT

PROPELLER SHAFT SPECIFICATIONS

Scheme 54

CAUTION

1. Wear appropriate work clothing, including a cap, protective goggles and protective shoes when performing any work.
2. Remove contamination including dirt and corrosion before removal, installation or disassembly.
3. Keep the disassembled parts in order and protect them from dust and dirt.
4. Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
5. Vehicle components are extremely hot after driving. Be wary of receiving burns from heated parts.
6. Use SUBARU genuine grease etc. or equivalent. Do not mix grease etc. of different grades or manufacturers.
7. Be sure to tighten fasteners including bolts and nuts to the specified torque.
8. Place shop jacks or rigid racks at the specified points.
9. Apply grease onto sliding or revolving surfaces before installation.
10. Before installing snap rings, apply sufficient amount of grease to avoid damage and deformation.
11. Before securing a part on a vise, place cushioning materials such as wood blocks, aluminum plates, or waste cloth between the part and the vise.

GENERAL TOOL

GENERAL TOOL CHART

JOINTS AND CONNECTORS

1. Remove the center exhaust pipe.
2. Remove the heat shield cover.
3. Check for any looseness of the yoke flange mounting bolts which connect to the rear differential and center bearing bracket mounting bolts.

Scheme 55

1. Remove the center exhaust pipe.
2. Remove the rear exhaust pipe and muffler.
3. Remove the heat shield cover.
4. Turn the propeller shaft by hand to see if abnormal free play exists at splines. Also move yokes to see if abnormal free play exists at spiders and bearings.

Scheme 56

1. Remove the center exhaust pipe.
2. Remove the rear exhaust pipe and muffler.
3. Remove the heat shield cover.
4. Set the dial gauge with its indicator stem at the center of the propeller shaft tube.
5. Turn the propeller shaft slowly by hands to check for runout of the propeller shaft. Runout: Limit: 0.6 mm (0.024 in)

Scheme 57

1. Remove the front and center exhaust pipes.
2. Remove the rear exhaust pipe and muffler.
3. Remove the heat shield cover.
4. Move the propeller shaft near the center bearing up, down, left, right by hand, to check for any abnormal free play of the bearings.

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

1. Lift up the vehicle, and then remove the front wheels.
2. Lift the crimped section of axle nut.
3. Remove the axle nut using a socket wrench while depressing the brake pedal. CAUTION: Remove the wheel before loosening the axle nut. Failure to follow this rule may damage the hub bearings.
4. Remove the stabilizer link.
5. Remove the disc brake caliper from the housing, and suspend it from strut using a wire.
6. Remove the disc rotor from the hub. NOTE: If it is difficult to remove the disc rotor from the hub, drive the 8 mm bolt into the threaded end of rotor, and then remove the rotor.
7. Remove the cotter pin and castle nut securing the tie-rod end to the housing knuckle arm.
8. Using a puller, remove the tie-rod ball joint from knuckle arm.
9. Remove the front ABS wheel speed sensor.
10. Remove the bolts which secure the sensor harness to the strut.
11. Remove the front arm ball joint from the housing.
12. Remove the front drive shaft from the transmission.
13. Remove the front drive shaft assembly from the hub. If it is hard to remove, use the ST. ST1 926470000 AXLE SHAFT PULLER ST2 28099PA110 AXLE SHAFT PULLER PLATE
14. After scribing an alignment mark on camber adjusting bolt head, remove the bolts which connect the housing and strut, and disconnect the housing from strut.

Scheme 68

Scheme 69

1. Align the alignment mark on the camber adjusting bolt head, and tighten the housing and strut using a new self-locking nut. Tightening torque: 155 N.m (15.81 kgf-m, 114.3 ft-lb)
2. Install the front drive shaft. < Ref. to «INSTALLATION»(ref-465404-S19689533262012042000000) , Front Drive Shaft. >
3. Install the front arm ball joint to the housing. Tightening torque: 50 N.m (5.10 kgf-m, 36.9 ft-lb)
4. Install the front ABS wheel speed sensor harness to the strut.
5. Install the front ABS wheel speed sensor on the housing. Tightening torque: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
6. Install the disc rotor to hub.
7. Install the disc brake caliper on the housing. Tightening torque: 80 N.m (8.16 kgf-m, 59 ft-lb)
8. Install the stabilizer link.
9. Connect the tie-rod end ball joint to the knuckle arm with a castle nut. CAUTION: When connecting the tie-rod, do not hit the cap at bottom of tie-rod end with a hammer. Tightening torque: 27 N.m (2.75 kgf-m, 19.9 ft-lb)
10. Tighten the castle nut to specified torque and tighten further within 60° until the pin hole is aligned with the slot in the nut. Bend the cotter pin to lock.
11. While depressing the brake pedal, tighten a new axle nut to the specified torque and lock it securely. CAUTION: Do not apply weight to the front axle before tightening the axle nut. Doing so may damage the hub bearing. Do not overtighten the nuts as this may damage the hub bearing. Tightening torque: 220 N.m (22.43 kgf-m, 162.3 ft-lb)
12. After tightening the axle nut, lock it securely.
13. Install the wheel. Tightening torque: 100 N.m (10.20 kgf-m, 73.8 ft-lb)
14. Inspect the wheel alignment and adjust if necessary. < Ref. to «INSPECTION»(ref-465402-S04135923322012042000000) , Wheel Alignment. >
15. Perform reinitialization of the auto headlight beam leveler system, (model with auto headlight beam leveler) < Ref. to «PROCEDURE»(ref-465411-S33802360402012042000000) , Auto Headlight Beam Leveler System. >

Scheme 70

Scheme 71

1. Remove the four bolts from the housing (A), and remove the front hub unit bearing and disc cover. CAUTION: Do not get closer the tool which charged magnetism to magnetic encoder. Be careful not to damage the magnetic encoder.
2. Disassemble the front hub unit bearing. < Ref. to «DISASSEMBLY»(ref-465404-S33027418512012042000000) , Front Hub Unit Bearing. >

Scheme 72

1. Assemble the front hub unit bearing. < Ref. to «ASSEMBLY»(ref-465404-S33027418512012042000000) , Front Hub Unit Bearing. >
2. Place the disc cover between housing (A) and front hub unit, and tighten the four bolts. Tightening torque: 65 N.m (6.63 kgf-m, 47.9 ft-lb) CAUTION: Do not get closer the tool which charged magnetism to magnetic encoder. Be careful not to damage the magnetic encoder.

Scheme 73

Scheme 74

1. Moving the front tire up and down by hand, check there is no play in bearing, and check the wheel rotates smoothly.
2. Inspect the lean of axis direction using a dial gauge. Replace the bearing if the load range exceeds the limitation. Service limit: Maximum: 0.05 mm (0.0020 in)

Scheme 75

Scheme 76

1. Lift up the vehicle, and then remove the front wheels.
2. Lift the crimped section of axle nut.
3. Remove the axle nut using a socket wrench while depressing the brake pedal. CAUTION: Remove the wheel before loosening the axle nut. Failure to follow this rule may damage the wheel bearings.
4. Remove the front ABS wheel speed sensor.
5. Remove the disc brake caliper from the housing, and suspend it from strut using a wire.
6. Remove the disc rotor from the hub. NOTE: If it is difficult to remove the disc rotor from the hub, drive the 8 mm bolt into the threaded end of rotor, and then remove the rotor.
7. Remove the four bolts from the housing (A). CAUTION: Do not get closer the tool which charged magnetism to magnetic encoder. Be careful not to damage the magnetic encoder.
8. Remove the front hub unit bearing. If it is hard to remove, use the ST. ST1 926470000 AXLE SHAFT PULLER ST2 28099PA110 AXLE SHAFT PULLER PLATE

BUSHING

For the removal procedure of bushing, refer to "Rear Trailing Link" in "REAR SUSPENSION". < Ref. to REAR HOUSING BUSHING , DISASSEMBLY, Rear Trailing Link. >

REAR HUB UNIT BEARING

Assemble each part in the reverse order of disassembly.

Tightening torque

Rear hub unit bearing

65 N.m (6.63 kgf-m, 47.9 ft-lb)

For the installation procedure of bushing, refer to "Rear Trailing Link" in "REAR SUSPENSION". < Ref. to REAR HOUSING BUSHING , ASSEMBLY, Rear Trailing Link. >

Scheme 77

1. Moving the rear tire up and down by hand, check that there is no backlash in bearing, and check that the wheel rotates smoothly.
2. Inspect the lean of axis direction using a dial gauge. Replace the bearing if the load range exceeds the limitation. Service limit: Maximum: 0.05 mm (0.0020 in)

Scheme 78

Scheme 79

1. Disconnect the ground cable from battery.
2. Lift up the vehicle, and then remove the rear wheels.
3. Lift the crimped section of axle nut.
4. Remove the axle nut using a socket wrench while depressing the brake pedal. CAUTION: Remove the wheel before loosening the axle nut. Failure to follow this rule may damage the wheel bearings.
5. Remove the disc brake caliper from the rear housing, and suspend it from vehicle using a string.
6. Remove the rear disc rotor.
7. Remove the four bolts from the rear housing.
8. Remove the rear hub unit bearing. CAUTION: Be careful not to damage the magnetic encoder. Do not get closer the tool which charged magnetism to magnetic encoder. NOTE: If it is hard to remove, use the ST. ST1 926470000 AXLE SHAFT PULLER ST2 28099PA110 AXLE SHAFT PULLER PLATE

Scheme 80

1. Aligning with the mounting hole of the rear brake back plate, temporarily tighten the rear hub unit bearing to the rear housing. CAUTION: Be careful not to damage the magnetic encoder. Do not get closer the tool which charged magnetism to magnetic encoder.
2. Tighten the four bolts of the rear housing. Tightening torque: 65 N.m (6.63 kgf-m, 47.9 ft-lb)
3. Tighten the new axle nut temporarily. CAUTION: Use new axle nuts.
4. Install the rear disc rotor.
5. Install the disc brake caliper on the rear housing. Tightening torque: 66 N.m (6.73 kgf-m, 48.7 ft-lb)
6. Install the brake hose bracket and rear ABS wheel speed sensor. Tightening torque: Brake hose bracket 33 N.m (3.36 kgf-m, 24.3 ft-lb) Rear ABS wheel speed sensor 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
7. While pressing the brake pedal, tighten the new axle nuts to the specified torque. CAUTION: Do not install wheel and let it touch the ground before tightening the axle nut. Failure to follow this rule may damage the axle bearing. Do not overtighten the nuts as this may damage the axle bearing. Tightening torque: 190 N.m (19.37 kgf-m, 140.1 ft-lb)
8. After tightening the axle nut, lock it securely.
9. Install the rear wheels. Tightening torque: 100 N.m (10.20 kgf-m, 73.8 ft-lb)
