Vehicle Dynamics Control (Vdc) (Diagnostics): Overview Subaru Forester SH рестайлинг

OPERATION

1. On << Main Menu >> display, select {Each System Check}.
2. On << System Selection Menu >> display, select {Brake Control System}.
3. Click the [OK] button after the {VDC} is displayed.
4. On << Brake Control Diagnosis >> display, select {Diagnostic Code(s) Display}.
5. Record the DTC and data. NOTE: For detailed operation procedures, refer to the appropriate procedure . For details concerning DTCs, refer to "List of Diagnostic Trouble Code (DTC)". < Ref. to «LIST OF DIAGNOSTIC TROUBLE CODE (DTC)»(ref-465420-S13173420902012042000000) . > Up to 3 DTCs are displayed in the order of detection. If a particular DTC is not stored in memory properly at the occurrence of problem (due to a drop in VDCCM&H/U power supply etc.), the "DTC suffixed with a question mark"? is displayed on Subaru Select Monitor display screen. This shows it may be an unreliable reading.

SUBARU SELECT MONITOR DISPLAY CONTENTS

1. On the << Main Menu >> display, select {Each System Check}.
2. On the << System Selection Menu >>, select {Brake Control System}.
3. Click the [OK] button after the {VDC} is displayed.
4. On the << Brake Control Diagnosis >>, select {Clear Memory}.
5. When the "Clear Memory?" is shown on the screen, click the [YES] button.
6. When "Done" and "Turn Ignition Switch OFF" are shown on the display screen, turn the ignition switch to OFF. NOTE: For detailed operation procedure, refer to the appropriate procedure .

Scheme 1

1. When warning lights or indicator lights do not illuminate in accordance with this illumination pattern, there must be an electrical malfunction.
2. When warning lights or indicator lights remain constantly OFF, check the combination meter circuit or CAN communication circuit. < Ref. to «ABS WARNING LIGHT, VDC OFF INDICATOR LIGHT, VDC WARNING LIGHT AND VDC INDICATOR LIGHT DO NOT COME ON»(ref-465420-S37083780942012042000000) , Warning Light Illumination Pattern. > < Ref. to «HILL START ASSIST WARNING LIGHT DOES NOT COME ON»(ref-465420-S38158713602012042000000) , Warning Light Illumination Pattern. >
3. When the ABS warning light, VDC OFF indicator light, VDC warning light & VDC indicator light, and hill start assist warning light do not go off, check the combination meter circuit and CAN communication circuit. < Ref. to «ABS WARNING LIGHT DOES NOT GO OFF»(ref-465420-S31800282482012042000000) , Warning Light Illumination Pattern. > < Ref. to «VDC OFF INDICATOR LIGHT DOES NOT GO OFF»(ref-465420-S31263311692012042000000) , Warning Light Illumination Pattern. > < Ref. to «VDC WARNING LIGHT AND VDC INDICATOR LIGHT DO NOT GO OFF»(ref-465420-S30812058162012042000000) , Warning Light Illumination Pattern. > < Ref. to «HILL START ASSIST WARNING LIGHT DOES NOT GO OFF»(ref-465420-S28713291272012042000000) , Warning Light Illumination Pattern. > NOTE: Even though the ABS warning light does not go off after 2 seconds from ABS warning light illumination, the ABS system operates normally when the warning light goes off while driving at approximately 12 km/h (7 MPH). However, the ABS system does not work while the ABS warning light is illuminated. It may take several minutes before the VDC warning light & VDC indicator light goes off, if the vehicle is parked under low temperature for a specified time. This is not defective because it is resulted from low engine coolant temperature. With the vehicle jack-up/lift-up or set on free rollers, when the wheels lock or spin after starting the engine, ABS warning light, and VDC warning light & VDC indicator light may illuminate because VDCCM&H/U detects the abnormal conditions from ABS wheel speed sensors. In this case, this is not a malfunction. Perform the Clear Memory Mode. < Ref. to «CLEAR MEMORY MODE»(ref-465420-S33461814672012042000000) . >
