Mechanism & Function - Brake System: Overview Subaru Forester SH

Scheme 1

1. Each of the front and rear disk brakes consist of a brake caliper, brake pads, and a brake disk rotor.
2. The front disc brakes are of a ventilated disc type which features high heat dissipation and superb braking stability. The rear disk brakes are either a ventilated disk type or a solid disk type.
3. Each disc rotor, which is fitted on the outside of the hub, is secured together with the wheel using the hub bolts. This facilitates its removal and installation.
4. The brake pads have a wear indicator which gives a warning when the pad is worn down to the limit.
