Power Steering System: Component Locations Subaru Forester SH

SPECIAL TOOL

SPECIAL TOOL DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 925711000 PRESSURE GAUGE Used for measuring oil pressure. 926200000 STAND Used when inspecting characteristic of gearbox assembly and disassembling it. Used together with BOSS D (34199AG000). 34099AC010 ADAPTER HOSE A Used together with PRESSURE GAUGE (925711000). 34099AC020 ADAPTER HOSE B Used together with PRESSURE GAUGE (925711000). 926230000 SPANNER For the lock nut when adjusting backlash of gearbox. 34099PA100 SPANNER Used when measuring the rotating resistance of gearbox assembly. 34099FA060 PUNCH HOLDER Used for crimping. 34099FA080 PUNCH Used to remove crimps. 34199AE090 PLUG WRENCH Used for removing the plug. 34199AE100 OIL SEAL PLUG REMOVER Used for removing oil seal plug. 34199AE110 OIL SEAL PLUG INSTALLER Used for installing the oil seal plug. 34199AE120 GEAR BOX OIL SEAL REMOVER Used to remove the oil seal of the gearbox. 34199AE130 GEAR BOX OIL SEAL INSTALLER Used for attaching the gear box oil seal. 34199FE040 INSTALLER A, B, C Used for installing the oil seal to the rack assembly. 34199FE010 REMOVER Used to remove the backup ring and oil seal. 34199FE050 GUIDE Used for installing the rack and seal to the housing assembly. 34199FE000 INSTALLER & REMOVER Used for removing and installing the rack oil seal (outer & inner). 34199FE060 INSTALLER Used for installing the rack oil seal (outer). 34199FE020 BASE Used for crimping. 34199AG000 BOSS D Used when inspecting characteristic of gearbox assembly and disassembling it. Used together with STAND (926200000)

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

1. Disconnect the ground cable from the battery.
2. Set the tire to the straight-ahead position.
3. Remove the airbag module. Refer to «REMOVAL»(ref-325330-S32011969732009071800000) , Driver's Airbag Module . WARNING: Always refer to "Airbag System" before performing service on the airbag modules. Refer to «CAUTION»(ref-325330-S05668494092009071800000) , General Description .
4. Place alignment marks on the steering wheel and steering shaft.
5. Remove the steering wheel nut, and then draw out the steering wheel from shaft using steering puller.
