Engine Ignition System - Ignition (H4SO): Removal & Installation Subaru Forester SH

Ignition System 5 illustrations ~130 words

REMOVAL

Spark plug

Refer to "SPECIFICATION" for the spark plug . Refer to SPECIFICATION , General Description .

Scheme 17

Scheme 17: RH SIDE
Scheme 17: RH SIDE

Scheme 18

Scheme 18
Scheme 18
  1. Disconnect the ground cable from the battery.
  2. Remove the air cleaner case. Refer to «REMOVAL»(ref-325315-S39932705032009071800000) , Air Cleaner Case .
  3. Remove the spark plug cords by pulling the boot. (Do not pull the cord itself.)
  4. Remove the spark plug with a spark plug socket.

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20: LH SIDE
Scheme 20: LH SIDE
  1. Remove the battery. Refer to «REMOVAL»(ref-325316-S34905635202009071800000) , Battery .
  2. Remove the spark plug cords by pulling the boot. (Do not pull the cord itself.)
  3. Remove the spark plug with a spark plug socket.

Scheme 21

Scheme 21
Scheme 21

INSTALLATION

Install in the reverse order of removal.

Tightening torque: 6.4 N.m (0.7 kgf-m, 4.7 ft-lb)

CAUTIONConnect the spark plug cords to correct positions. Failure to do so will damage the unit.
