MAINTENANCE
- Maintenance instructions for serviceable parts describe work area and detailed step with illustration. It also describes the use of special tool, tightening torque, caution for each procedure.
- If many serviceable parts are included in one service procedure, appropriate reference is provided for each parts.
Example
Scheme 40
BRAKE FLUID
If brake fluid gets in your eyes or on your skin, do the following
- Wash eyes and seek immediate medical attention.
- Wash your skin with soap and then rinse thoroughly with water.
PROTECTING VEHICLE UNDER MAINTENANCE
Make sure to attach the fender cover, seat covers, etc. before work.
FLUID
Use the fluids specified in the chart below. Do not mix two different kinds or makes of fluid.
| CAUTION | For AT model, be sure to use the recommended ATF or equivalent. Otherwise it will cause trouble. |
| Fluid | Recommended materials | Item number | Alternative |
|---|---|---|---|
| Automatic transmission fluid | SUBARU ATF HP | Idemitsu: ATF HP | |
| Power steering fluid | SUBARU ATF HP | DEXRON III | |
| Brake fluid | FMVSS No. 116 DOT3 | ||
| Clutch fluid | FMVSS No. 116 DOT3 | FMVSS No. 116 DOT4 |
FLUID RECOMMENDED NUMBER CHART
POWER STEERING FLUID LEVEL
Note. When power steering fluid temperature is 20°C (68°F), read the fluid level on the "COLD" side. When power steering fluid temperature is 80°C (176°F), read the fluid level on the "HOT" side.
Scheme 41
- Stop the engine to park the vehicle on a level surface.
- Check the fluid level using the scale on the outside of the reservoir tank. If the level is below "MIN", fill fluid up to "MAX" level. CAUTION: If any power steering fluid is spilt on the exhaust pipe, wipe it off with a clean cloth to avoid emitting smoke or causing a fire. NOTE: If fluid level is at "MAX" level or above, drain fluid to keep the level in the specified range of indicator by using a syringe or the like. Recommended fluid: Refer to «FLUID»(ref-325297-S20074697792009071800000) , RECOMMENDED MATERIALS, Recommended Materials. Fluid capacity: Refer to «CAPACITY»(ref-325297-S11964400482009071800000) , Forester.
POWER STEERING FLUID FOR LEAKS
Inspect the underside of oil pump and gearbox of power steering system, hoses, pipes and their couplings for fluid leaks.
If the fluid leaks are found, retighten their fitting bolts (or nuts) and/or replace their parts.
| CAUTION | Also pay attention to interference between hoses or pipes and other parts when inspecting fluid leaks. |
