Vehicle Dynamics Control (Vdc): Specifications Subaru Forester SH

Anti-Lock/traction Control 4 illustrations

SPECIFICATION

Item				Specification or identification
ABS wheel speed sensor	ABS wheel speed sensor gap (for reference)	Front		0.77 - 1.43 mm (0.030 - 0.056 in)
	ABS wheel speed sensor gap (for reference)	Rear		0.64 - 1.56 mm (0.025 - 0.061 in)
	Identifications of harness (marks, color)	Front	RH	K1 (White)
		Front	LH	K2 (Yellow)
		Rear	RH	P3 (light blue)
		Rear	LH	P4 (brown)
VDCCM & H/U Identification		AT		Z1
VDCCM & H/U Identification		MT		Z2

ABS WHEEL SPEED SENSOR SPECIFICATION CHART

Scheme 52: ABS WHEEL SPEED SENSOR

Scheme 53: YAW RATE & LATERAL G SENSOR

Scheme 54: STEERING ANGLE SENSOR

Scheme 55: VDC CONTROL MODULE & HYDRAULIC CONTROL UNIT (VDCCM & H/U)
