Instrument cluster — Instrument cluster circuit Subaru Forester SG facelift
All systems — 33 systems
- Air conditioning 2
- Anti-lock brakes 2
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan 2.5l
- Cooling fan 2.5l turbo
- Cruise control 2.5l
- Cruise control 2.5l turbo
- Defoggers 3
- Engine performance 2.5l
- Engine performance 2.5l turbo
- Exterior lights 2
- Ground distribution
- Headlights 3
- Horn
- Instrument cluster
- Interior lights 2
- Power distribution
- Power door locks 2
- Power mirrors 3
- Power seats 2
- Power top/sunroof
- Power windows
- Radio
- Shift interlock
- Starting/charging 2
- Starting/charging 2.5l
- Starting/charging 2.5l turbo
- Supplemental restraints
- Transmission
- Warning systems
- Wiper/washer 2
Components on these wiring diagrams 32
Click a component to highlight it on every diagram it appears on.
