OPERATION CHECK (WITHOUT GAUGES)

Scheme 19

Scheme 20

1. CHECKING WITHOUT GAUGES This method cannot determine the exact portion which has failed, but it can provide a rough understanding of the nature of failure if checking is conducted in accordance with the following procedures.
2. AIR TIGHTNESS CHECK Start the engine, and run it for 1 to 2 minutes, then turn it off. Depress the brake pedal several times applying same pedal force as that used in ordinary braking operations. The pedal stroke should be greatest on 1st depression, and it should become smaller with each successive depression. If no change occurs in the pedal height while in a depressed state, the brake booster is faulty. NOTE: In the event of defective operation, inspect the condition of check valve and vacuum hose. Replace them if faulty and conduct the test again. If no improvement is observed, check precisely with gauges.
3. OPERATION CHECK With the engine off, depress the brake pedal several times applying same pedal force and make sure that pedal height does not vary with each depression of pedal. With the brake pedal depressed, start the engine. As the engine starts, the brake pedal should move slightly toward the floor. If no change occurs in the pedal height, the brake booster is faulty. NOTE: If faulty, check precisely with gauges.
4. LOADED AIR TIGHTNESS CHECK Depress the brake pedal while engine is running, and turn off the engine while pedal is still depressed. Keep the pedal depressed for 30 seconds; if no change occurs in the pedal height, the brake booster is functioning normally; if the pedal height increases, it is faulty. NOTE: If faulty, check precisely with gauges.

OPERATION CHECK (WITH GAUGES)

Scheme 21

Scheme 22

Scheme 23

1. CHECKING WITH GAUGES Connect gauges as shown in the figure. After bleeding air from pressure gauges, proceed to each check.
2. AIR TIGHTNESS CHECK Start the engine and keep it running until a vacuum of 66.7 kPa (500 mmHg, 19.69 inHg) = point A is indicated on vacuum gauge. Do not depress the brake pedal. Stop the engine and watch the gauge. If the vacuum drop range is less than 3.3 kPa (25 mmHg, 0.98 inHg) within 15 seconds after stopping engine, the brake booster is functioning properly. If defective, the cause may be one of those listed below. Check valve malfunction Leak from vacuum hose Leak from the shell jointed portion or stud bolt welded portion Damaged diaphragm Leak from valve body seal and bearing portion Leak from plate and seal assembly portion Leak from poppet valve assembly portion
3. LOADED AIR TIGHTNESS CHECK Start the engine and depress brake pedal with pedal force of 196 N (20 kgf, 44 lb). Keep the engine running until a vacuum of 66.7 kPa (500 mmHg, 19.69 inHg) = point B is indicated on vacuum gauge while the pedal is still depressed. Stop the engine and watch vacuum gauge. If the vacuum drop range is less than 3.3 kPa (25 mmHg, 0.98 inHg) within 15 seconds after stopping engine, the brake booster is functioning properly. If defective, refer to "AIR TIGHTNESS CHECK". < Ref. to «INSPECTION»(ref-274217-S28051601402007121400000) , Brake Booster. > If any fault is found on brake booster, replace the brake booster with a new one.
4. LACK OF BOOSTING ACTION CHECK Turn off the engine, and set the vacuum gauge reading at "0". Then, check the fluid pressure when brake pedal is depressed. The pressure must be greater than the standard value listed. BRAKE PEDAL FORCE SPECIFICATIONS Brake pedal force 147 N (15 kgf, 33 lb) 294 N (30 kgf, 66 lb) Fluid pressure 648 kPa (7 kg/cm 2 , 94 psi) 1,715 kPa (17 kg/cm 2 , 249 psi)
5. BOOSTING ACTION CHECK Set the vacuum gauge reading at 66.7 kPa (500 mmHg, 19.69 inHg) by running engine. Then, check the fluid pressure when brake pedal is depressed. The pressure must be greater than the standard value listed. BRAKE PEDAL FORCE SPECIFICATIONS Brake pedal force 147 N (15 kgf, 33 lb) 294 N (30 kgf, 66 lb) Fluid pressure 6,468 kPa (66 kg/cm 2 , 938 psi) 10,240 kPa (104 kg/cm 2 , 1,485 psi)

Scheme 24

1. Remove the brake pipe from proportioning valve at four places.
2. Remove the proportioning valve from its bracket.

Note. Do not disassemble or adjust the proportioning valve. (The proportioning valve must be replaced as an assembly.)
