Fuel Injection (Fuel Systems) (H4DOTC): Specifications Subaru Forester SG рестайлинг

Fuel System 8 illustrations ~195 words

SPECIFICATION

Fuel tankCapacity60 l (15.9 US gal, 13.2 Imp gal)
LocationUnder rear seat
Fuel pumpTypeImpeller
Shutoff discharge pressure450 - 677 kPa (4.59 - 6.9 kg/cm 2 , 65.27 - 98.2 psi)
Discharge rate145 l (38.3 US gal, 31.9 Imp gal)/h or more [300 kPa, 12 V (3.06 kg/cm 2 , 43.5 psi)]
Fuel filterIntank type

GENERAL SPECIFICATION

Exploded View Of Intake Manifold With Torque Specifications. Scheme 227

Scheme 227: Exploded View Of Intake Manifold With Torque Specifications

Exploded View Of Air Intake System With Torque Specification. Scheme 228

Scheme 228: Exploded View Of Air Intake System With Torque Specification

Identifying Crankshaft, Camshaft And Knock Sensors With Torque Specification. Scheme 229

Scheme 229: Identifying Crankshaft, Camshaft And Knock Sensors With Torque Specification

Exploded View Of Fuel Tank With Torque Specification. Scheme 230

Scheme 230: Exploded View Of Fuel Tank With Torque Specification

Exploded View Of Fuel Line With Torque Specification. Scheme 231

Scheme 231: Exploded View Of Fuel Line With Torque Specification

Exploded View Of Fuel Filler Pipe With Torque Specification. Scheme 232

Scheme 232: Exploded View Of Fuel Filler Pipe With Torque Specification

The tumble generator valve position sensor cannot be adjusted when installed, so it should not be removed from the tumble generator valve assembly. Refer to " TUMBLE GENERATOR VALVE ASSEMBLY " for removal and installation procedure. REMOVAL TUMBLE GENERATOR VALVE ASSEMBLY.> INSTALLATION TUMBLE GENERATOR VALVE ASSEMBLY. >

Scheme 233

Scheme 233

Scheme 234

Scheme 234
  1. Disconnect the ground cable from battery. (Scheme 233): Disconnecting Battery Ground Cable
  2. Disconnect the engine harness connector (A) from bracket.
  3. Disconnect the connector (B) from wastegate control solenoid valve.
  4. Remove the bracket from vehicle body. (Scheme 234): Identifying Engine Harness And Wastegate Control Solenoid Valve Connector
  5. Disconnect the pressure hose (C) from the wastegate control solenoid valve. see scheme 155: Identifying Pressure Hoses
  6. Remove the wastegate control solenoid valve from the bracket
