Brakes - ABS: Adjustments Subaru Forester SG рестайлинг

ADJUSTMENT

Adjust the gap using spacers (Part No. 26755AA000).

Scheme 52

1. Disconnect the ground cable from battery.
2. Lift-up the vehicle.
3. Remove the rear seat and disconnect the rear ABS wheel speed sensor connector.
4. Remove the rear sensor harness bracket from the rear trailing link and bracket.
5. Remove the rear ABS wheel speed sensor from the back plate. CAUTION: Be careful not to damage the pole piece and the face of the teeth located at tip of the sensor during removal. Do not pull on the sensor harness during removal.
6. Remove the rear tone wheel when removing the hub from the housing and hub assembly. REMOVAL Rear Axle . >

Scheme 53

Scheme 54

1. Attach the hub to the rear tone wheel and attach the rear housing. ASSEMBLY . >
2. Temporarily attach the rear ABS wheel speed sensor to the back plate. CAUTION: Be careful not to hit the ABS wheel speed sensor pole piece and tone wheel against adjacent metal parts during installation.
3. Install the rear drive shaft to the rear housing and rear differential spindle. INSTALLATION Rear Axle . >
4. Install the rear sensor harness on the rear trailing link. Tightening torque: 33 N.m (3.4 kgf-m, 24.6 ft-lb)
5. Check the clearance of the sensor. SENSOR GAP INSPECTION, REAR ABS WHEEL SPEED SENSOR. > When the clearance is within standard values, tighten the ABS wheel speed sensor to the back plate at the specified torque. If clearance is outside of the standard value, readjust by using the spacer (Part No. 26755AA000). ABS wheel speed sensor gap standard value: 0.7 - 1.2 mm (0.028 - 0.047 in) Tightening torque: 33 N.m (3.4 kgf-m, 24.6 ft-lb) NOTE: Check the identification (mark) on the harness to make sure there is no warpage. (RH: White, LH: Yellow)
6. After confirmation of the ABS wheel speed sensor clearance, connect the connector to the ABS wheel speed sensor.
7. Connect the ground cable to the battery.

Adjust the gap using spacers (Part No. 26755AA000).
