SPECIFICATIONS
| Model | Non-turbo | Turbo | |
|---|---|---|---|
| Front | Camber (allowance: ++/-0 °45', differences between RH and LH: 45' or less) | 0°25' | |
| Caster (Reference) | 3°03' | ||
| Toe-in | 0++/-3 mm (0++/-0.12 in) Toe angle (sum of both wheels): 0°++/-0°15' | ||
| Kingpin angle (Reference) | 13°12' | ||
| Wheel arch height (tolerance: +12 / -24 mm (+0.47/-0.94 in) | 437 mm (17.20 in) | ||
| Diameter of stabilizer | 21 mm (0.83 in) | ||
| Rear | Camber (allowance: ++/-0°45', differences between RH and LH: 45' or less) | 0°50' | 0°55' |
| Toe-in | 2++/-3 mm (0.079++/-0.12 in) Toe angle (sum of both wheels): 0°10'++/-0°15' | ||
| Thrust angle | 0°++/-30' | ||
| Wheel arch height (tolerance: +12 / -24 mm (+0.47/-0.94 in) | 440 mm (17.32 in) | 435 mm (17.13 in) | |
| Diameter of stabilizer | 17 mm (0.67 in) | ||
GENERAL SPECIFICATIONS
Note. Front and rear toe-ins and front camber can be adjusted. If toe-in or camber tolerance exceeds specifications, adjust toe-in and camber to the middle value of specification. The other items indicated in the specification table cannot be adjusted. If the other items exceeds specifications, check suspension parts and connections for deformities; replace with new ones as required.
