UNDER-DASH FUSE/RELAY BOX

Note. Under-dash fuse/relay box is located under instrument panel behind the coin tray on driver's side, see illustration below.

Scheme 1: UNDER-DASH FUSE/RELAY BOX

Fuse No.	Fuse Rating	Circuit
1	15A	Heater Fan
2	15A	Heater Fan
3	15A	Power Door Lock & Remote Keyless entry
4	15A	Cigarette Lighter & Remote Controlled Rear View Mirrors
5	10A	Tail Light & Parking Light
6	15A	SRS Air Bag
7	15A	Fog Light
8	30A	ABS Vehicle Dynamics Control system (models with VDC systems only)
9	15A	Radio
10	N/A	N/A
11	15A	Engine Ignition System, SRS Air Bag, & A/T Control System
12	10A	Illumination Brightness Control
13	20A	Wiper Deicer & Outside Mirror Defogger
14	10A	Meter
15	30A	Windshield Wiper & Washer
16	20A	Brake Light
17	15A	Air Conditioner
18	15A	Backup Light & Cruise Control
19	15A	Power Outlet (Cargo)
20	10A	Rear Window Wiper & Washer
21	15A	Ignition Coil (Non-turbo models only)
22	15A	Seat Heater
23	N/A	N/A

UNDER-DASH FUSE/RELAY BOX LEGEND

Note. Under-hood fuse/relay box is located in the side of engine compartment, see illustration below.

Scheme 3: UNDER-HOOD FUSE/RELAY BOX

Fuse No.	Fuse Rating	Circuit
A		FWD Socket (AT models without Vehicle Dynamics Control system)
B		Main Fuses
1	30A	Radiator Cooling Fan (Main)
2	30A	Radiator Cooling Fan (Sub)
3	50A	Vehicle Dynamics Control system (models with VDC systems only)
3	30A	ABS Motor
4	30A	Engine Sensor (Non-turbo models only)
5	20A	Rear Window Defogger
6	15A	Hazard Warning Flasher, Horn
7	15A	Turn Signal Lights
8	10A	Automatic Transmission Control Unit
9	10A	Alternator
10	15A	Headlight (Right side)
11	15A	Headlight (Left side)
12	20A	Lighting Switch
13	15A	Clock, Interior Light
14	10A	Secondary Air Combi Valve (Turbo models only)

UNDER-HOOD FUSE/RELAY BOX LEGEND
