PROCEDURE TO ADJUST THE CONCENTRATION OF THE COOLANT

To adjust the concentration of coolant according to temperature, find the proper fluid concentration in the above diagram and replace the necessary amount of coolant with an undiluted solution of SUBARU genuine coolant (concentration 50%).

The amount of engine coolant that should be replaced can be determined using the diagram.

[Example]

Assume that the engine coolant concentration must be increased from 25% to 40%. Find point A, where the 25% line of engine coolant concentration intersects with the 40% curve of the necessary engine coolant concentration, and read the scale on the vertical axis of the graph at height A. The quantity of coolant to be drained is 2.1 l ;(2.2 US qt, 1.8 Imp qt). Drain 2.1 l (2.2 US qt, 1.8 Imp qt) of coolant from the cooling system and add 2.1 l (2.2 US qt, 1.8 Imp qt) of the undiluted solution of SUBARU coolant.

If a coolant concentration of 50% is needed, drain all the coolant and refill with the undiluted solution only.

Scheme 20

Scheme 20: PROCEDURE TO ADJUST THE CONCENTRATION OF THE COOLANT

Scheme 21

Scheme 21: NON-TURBO MODEL

Scheme 22

Scheme 22

Scheme 23

Scheme 23

Scheme 24

Scheme 24

Scheme 25

Scheme 25
  1. Remove the radiator. REMOVAL RADIATOR. >
  2. Remove the V-belts. REMOVAL V-belt. >
  3. Remove the crank pulley. REMOVAL Crank Pulley. >
  4. Remove the timing belt. TIMING BELT REMOVAL, Timing Belt. >
  5. Remove the automatic belt tension adjuster.
  6. Remove the belt idler No. 2.
  7. Remove the cam sprocket (LH) using ST. ST 18231AA010 CAM SPROCKET WRENCH NOTE: CAMSHAFT SPROCKET WRENCH (499207100) can also be used.
  8. Remove the belt cover (LH) No. 2.
  9. Remove the tensioner bracket.
  10. Disconnect the hose from water pump.
  11. Remove the water pump.

Scheme 26

Scheme 26

Scheme 27

Scheme 27: TURBO MODEL

Scheme 28

Scheme 28

Scheme 29

Scheme 29

Scheme 30

Scheme 30

Scheme 31

Scheme 31
  1. Remove the radiator. REMOVAL RADIATOR. >
  2. Remove the V-belts. REMOVAL V-belt. >
  3. Remove the crank pulley. REMOVAL Crank Pulley. >
  4. Remove the timing belt. REMOVAL Timing Belt. >
  5. Remove the automatic belt tension adjuster (A).
  6. Remove the belt idler (B).
  7. Remove the belt idler No. 2 (C).
  8. Remove the camshaft position sensor. REMOVAL Camshaft Position Sensor. >
  9. Remove the cam sprocket (LH) using ST. ST 499977500 CAM SPROCKET WRENCH (Intake) ST 499207400 CAM SPROCKET WRENCH (Exhaust)
  10. Remove the belt cover (LH) No. 2.
  11. Remove the tensioner bracket.
  12. Disconnect the hose from water pump.
  13. Remove the water pump.

Scheme 32

Scheme 32: NON-TURBO MODEL
  1. Install the water pump onto cylinder block (LH). NOTE: Always use new gasket. When installing the water pump, tighten the bolts in two stages in alphabetical sequence as shown in figure. Tightening torque: First: 12 N.m (1.2 kgf-m, 8.9 ft-lb) Second: 12 N.m (1.2 kgf-m, 8.9 ft-lb)
  2. Install the hose to water pump.
  3. Install the tensioner bracket. Tightening torque: 25 N.m (2.5 kgf-m, 18.1 ft-lb)
  4. Install the belt cover No. 2 (LH). Tightening torque: 5 N.m (0.5 kgf-m, 3.6 ft-lb)
  5. Install the cam sprocket (LH) using ST. ST 18231AA010 CAM SPROCKET WRENCH NOTE: CAMSHAFT SPROCKET WRENCH (499207100) can also be used. Tightening torque: 78 N.m (8.0 kgf-m, 57.9 ft-lb)
  6. Install the belt idler No. 2. Tightening torque: 39 N.m (4.0 kgf-m, 28.9 ft-lb)
  7. Install the automatic belt tension adjuster which has tension rod held by pin. AUTOMATIC BELT TENSION ADJUSTER ASSEMBLY AND BELT IDLER INSTALLATION, Timing Belt. >
  8. Install the timing belt. TIMING BELT INSTALLATION, Timing Belt. >
  9. Install the crank pulley. INSTALLATION Crank Pulley. >
  10. Install the V-belts. INSTALLATION V-belt. >
  11. Install the radiator. INSTALLATION RADIATOR. >
