Automatic HVAC System 2 illustrations

WIRING DIAGRAM

AIR CONDITIONING in SYSTEM WIRING DIAGRAMS . >

Scheme 2

Scheme 2: OPERATION

Scheme 3

Scheme 3
StepCheckYesNo
1 SET SELF-DIAGNOSIS MODE BY OPERATING CONTROL PANEL. Turn the ignition switch to OFF. Set the air flow control dial to the AUTO position. Set the fan speed control dial to the AUTO position. Turn the ignition switch to ON while pressing the FRESH/RECIRC switch and the A/C switch. The A/C control panel LED will blink.Does the self-diagnosis function operate?Go to step 2.A/C OR SELF-DIAGNOSIS SYSTEMS DO NOT OPERATE DIAGNOSTICS FOR A/C SYSTEM MALFUNCTION. >
2 CHECK THE LIGHTING OF THE LED. Check whether the A/C control panel LED blinks. (Lighting and extinguishing repeated 8 times.)Are all LEDs blinking?Go to step 3.Go to step 5.
3 SENSOR MALFUNCTION CHECK. The A/C switch LED turns off and the sensor inspection is started, after the LED check is completed or when the rear defogger switch is pressed. Switch the air flow control dial to check the sensors. If there is no problem with the sensors, the FRESH/RECIRC switch LED will light, regardless of the position of the air flow control dial. NOTE: At this time, the rear defogger LED will light if there are previous failures. For current failures it will turn off. It is possible to judge whether there is an open or short circuit by using the blinking patterns of the FRESH/RECIRC switch.Does the LED of the FRESH/RECIRC switch illuminate?Go to step 4.Check the relationship of the air flow control dial position and sensors using the sensor check list, and check/repair sensors that have failed. SENSOR CHECK TABLE OPERATION, DIAGNOSTIC CHART FOR SELF-DIAGNOSIS. >
4 OPERATION CHECK OF ACTUATORS, COMPRESSOR AND FAN MOTOR. Press the A/C switch. (At this time, the A/C switch LED illuminates.)) Operate the fan speed control dial to check the operations of each of the actuator, compressor and fan motor. OPERATING MODE TABLE OPERATION, DIAGNOSTIC CHART FOR SELF-DIAGNOSIS. > NOTE: Switching the fan speed control dial position enables the individual check of each step.Do the actuators, compressor, and fan motor operate according to the operating mode table? OPERATING MODE TABLE OPERATION, DIAGNOSTIC CHART FOR SELF-DIAGNOSIS. >Either turn the fan control dial to the OFF position, or turn the ignition switch to the OFF position to quit the self-diagnosis function.Refer to each of the diagnostics for the actuator, compressor and fan motor to repair the areas that have malfunctioned. DIAGNOSTICS FOR A/C SYSTEM MALFUNCTION. > DIAGNOSTIC PROCEDURE FOR ACTUATORS. >
5 CHECK POOR CONTACT. Check poor contact of auto A/C control module connector.Is there poor contact in the auto A/C control module connector?Repair the poor contact in the auto A/C control module connector.Replace the auto A/C control module.
NOTE
At this time, the rear defogger LED will light if there are previous failures. For current failures it will turn off. It is possible to judge whether there is an open or short circuit by using the blinking patterns of the FRESH/RECIRC switch.
NOTE
Switching the fan speed control dial position enables the individual check of each step.

DIAGNOSTIC PROCEDURE CHART
