SYSTEM CALIBRATION
| CAUTION | If a trouble occurs during the system calibration resulting in stopping the process or interrupting sensor data read, the DTC 28 {Adjustment / Inspection halt} of occupant detection system will be detected to illuminate the airbag warning light. In this case, perform the system calibration again, or perform the system calibration again after repairing the trouble cause. Compartment temperature during the system calibration must be within 0 to 40°C. Perform the system adjusting after installing the seat to vehicle, when replace the occupant detection system or remove the passenger's seat. |
Scheme 160
Scheme 161
- Park vehicle on a level surface.
- Unload the cargo and set the vehicle in curb weight condition.
- Connect the Subaru Select Monitor to vehicle, and then turn the ignition switch to ON.
- Turn the Subaru Select Monitor power to ON.
- On the «Main Menu» display screen, select the {Each System Check} and press the [YES] key.
- On the «System Selection Menu» display screen, select the {Occupant detection system} and press the [YES] key.
- «LOAD CELL TYPE OCCUPANT DETECTION SYSTEM Press the [YES] key» is displayed, press the [YES] key.
- On the «OCCUPANT DETECTION SYSTEM» display screen, select the {1.System Calibration} and press the [YES] key.
- When the {Complete all calibration checks, illuminated and a trouble code saved. Continue: YES, Quit: NO} is displayed, press the [YES] key.
- When the {Diagnostic code check No trouble Continue: YES, Quit: NO} is displayed, press the [YES] key. NOTE: When a DTC is detected, {Diagnostic code check some troubles occur See in this information Press YES to END} is displayed. Inspect the DTC, and perform the calibration again after repairing trouble cause.
- When the {Empty the passenger seat Continue: YES, Quit: NO} is displayed, empty the passenger's seat and press the [YES] key.
- When {Adjust the passenger seat to the condition shown in this information Continue: YES, Quit: NO} is displayed, slide the passenger's seat to the rearmost position and make sure to lock into place. Lock the backrest at the frontmost position, and press the [YES] key. NOTE: After pressing the [YES] key, "Now processing ... Wait for a while. Do not touch or give impact to vehicle and seat" is displayed. Do not touch the vehicle for approximately 20 seconds while the message is displayed. When the {System calibration is unsuccessful See in this information Press YES to END} is displayed, go to 19 .
- When the {Threshold adjustment is success fully completed weight inspection in this information continue: YES, Quit: NO} is displayed, press the [YES] key.
- When the {Empty the passenger seat Continue: YES, Quit: NO} is displayed, make sure the passenger's seat is empty and press the [YES] key.
- When the {Adjust the passenger seat to the condition shown with this information Continue: YES, Quit: NO} is displayed, check the seat position and press the [YES] key. NOTE: Slide the seat to the rearmost position and lock it securely. Lock the backrest securely in the front-most position. (For the model with power seat, operate the slide switch or reclining switch fully until no longer moved.) Diagnostic trouble code (DTC) is input when selecting the "NO" in this step. After pressing the [YES] key, "Now processing ... Wait for a while. Do not touch or give impact to vehicle and seat" is displayed. Do not touch the vehicle for approximately 20 seconds while the message is displayed. When the {System calibration is unsuccessful See in this information Press YES to END} is displayed, go to 19 ).
- When {Input threshold weight mass (lbs) [00.0] Press YES after inputting weight mass} is displayed, enter the weight (79.1 lbs) and press the [YES] key. NOTE: When an incorrect weight amount is entered, error will be generated.
- When {Put threshold weight with the position on the passenger seat shown with this information Continue: YES, Quit: NO} is displayed, check the seat position, assemble SPECIAL TOOL WEIGHT A and WEIGHT B and place it on the passenger's seat, then press the [YES] key. ST1 98399AG000 SPECIAL TOOL WEIGHT A ST2 98399AG010 SPECIAL TOOL WEIGHT B NOTE: DTC is detected when selecting the "NO" in this step. Place the weight in the seat center, making sure the firm contact with the backrest. Do not touch or give any impact to the vehicle for approximately 20 seconds after pressing the [YES] key. When the {System calibration is unsuccessful See in this information Press YES to END} is displayed, go to step 19).
- When the {System calibration Is successfully completed Press YES to END} is displayed, press the [YES] key to finish the diagnosis.
- When the {System calibration is unsuccessful See in this information Press YES to END} is displayed, the system is malfunctioning. Read the DTC, repair the trouble cause, and then perform the system calibration again. READ DIAGNOSTIC TROUBLE CODE (DTC). > LIST OF DIAGNOSTIC TROUBLE CODE (DTC). >
| CAUTION | If the system calibration fails and stop the operation, DTC 28 {Adjustment/Inspection halt} will be recorded and airbag warning light will illuminate. If the DTC except {Adjustment/Inspection halt} is displayed, calibrate the system after the malfunction is repaired. |
DTC 28 ADJUSTMENT / INSPECTION HALT
DETECTING CONDITION
- Seat calibration is incomplete.
- A problem has occurred in the sensor or control module.
- Malfunction occurs on harness.
| CAUTION | If the system calibration or inspection service has been interrupted before completing, the indicator light of airbag system will come on and the DTC will be input. |
| Step | Check | Yes | No |
|---|---|---|---|
| 1 PERFORM SYSTEM CALIBRATION. Perform the system calibration for system using the Subaru Select Monitor. NOTE: For detail procedure, refer to " SYSTEM CALIBRATION ". SYSTEM CALIBRATION OPERATION, SUBARU SELECT MONITOR. > | Is the system calibration completed correctly? | Perform the Clear Memory Mode. SUBARU SELECT MONITOR. > Using the Subaru Select Monitor, check that DTC 28 is not displayed. | Go to step 2. |
| 2 CHECK DTC. Connect the Subaru Select Monitor to data link connector, and read the DTC. | Is DTC except "DTC 28 Adjustment / Inspection half displayed on Subaru Select Monitor? | Perform the inspection using "Diagnostic Procedure with Diagnostic Trouble Code (DTC)." DIAGNOSTIC PROCEDURE WITH DIAGNOSTIC TROUBLE CODE (DTC). > | Go to step 3. |
| 3 CHECK SEAT. NOTE: Remove materials interrupting seat slide or heavy materials in back pocket. | Is there a problem on each part of seat? / Reclining and slide mechanisms work smoothly, and the lock operates properly. / No deformation, cracks or leaning of the seat. | Go to step 4. | Replace problem parts. FRONT SEAT . > |
| 4 CHECK SEAT POSITION. | Is the seat set in the same position as the system calibration procedure? | Go to step 5. | Adjust the seat position according to system calibration procedure. SYSTEM CALIBRATION OPERATION, SUBARU SELECT MONITOR. > |
| 5 CHECK WEIGHT FOR SYSTEM CALIBRATION. | Is the weight designated for system calibration as special tool used? | Go to step 6. | Use the designated weight for system calibration as special tool and perform the system calibration. |
| 6 CHECK SERVICE ENVIRONMENT. Check that the service environment (compartment temperature) is within 0 to 40°C (32 to 104°F). | Is the compartment temperature within specifications? | Go to step 7. | Perform the system calibration after setting the compartment temperature within specifications. |
| 7 CHECK FLOOR PANEL. Check that floor panel at the seat installation has no distortion or damage. | Is there serious distortion or damage on the floor panel? | Go to step 8. | Perform the system calibration after repairing distortion or damage. |
| 8 PERFORM SYSTEM CALIBRATION. Perform the system calibration. SYSTEM CALIBRATION OPERATION, SUBARU SELECT MONITOR. > | Is the system calibration completed correctly? | Finish the diagnosis. | Go to step 9. |
| 9 REPLACE SEAT CUSHION FRAME ASSEMBLY. Replace backrest frame assembly and perform the system calibration. SYSTEM CALIBRATION OPERATION, SUBARU SELECT MONITOR. > | Is the system calibration completed correctly? | Finish the diagnosis. | Go to step 10 . |
| 10 REPLACE BACKREST FRAME ASSEMBLY. Replace backrest frame assembly and perform the system calibration. SYSTEM CALIBRATION OPERATION, SUBARU SELECT MONITOR. > | Is the system calibration completed correctly? | Finish the diagnosis. | Go to step 11 . |
| 11 INSTALL SPACER KIT. Remove the mounting bolt for seat cushion frame assembly. Install the spacer between seat cushion frame assembly RH and chassis. Using the bolts supplied, tighten the bolts for seat cushion frame assembly to specified torque. FRONT SEAT . > Perform the system calibration. | Is the system calibration completed correctly? | Finish the diagnosis. | Go to step 12 . |
| 12 INSTALL SPACER KIT. Remove spacer and bolt installed in RH side. Install the spacer between seat cushion frame assembly LH and chassis. Using the bolts supplied, tighten the bolts for seat cushion frame assembly to specified torque. FRONT SEAT . > Perform the system calibration. | Is the system calibration completed correctly? | Finish the diagnosis. | Perform diagnosis from step 1. |
| NOTE |
|---|
| For detail procedure, refer to " SYSTEM CALIBRATION ". SYSTEM CALIBRATION OPERATION, SUBARU SELECT MONITOR. > |
| NOTE |
|---|
| Remove materials interrupting seat slide or heavy materials in back pocket. |
