Wiring diagram: Instrument cluster — Instrument cluster circuit Subaru Forester SF facelift
All systems — 27 systems
- Air conditioning
- Anti-lock brakes
- Anti-theft
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers 3
- Engine performance 2.5l
- Exterior lights 2
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster
- Interior lights
- Power distribution
- Power door locks
- Power mirrors
- Power seats
- Power top/sunroof
- Power windows
- Radio
- Shift interlocks
- Starting/charging 2
- Supplemental restraints 2
- Transmission
- Warning systems
- Wiper/washer 2
Components on these wiring diagrams 34
Click a component to highlight it on every diagram it appears on.
