Power Windows: Diagnosis Subaru Forester SF

Windows 3 illustrations ~152 words

TROUBLE SHOOTING

Note. Information is not available.

POWER WINDOW MAIN SWITCH TEST

Remove power window main switch from driver's door panel. Disconnect harness connector. Continuity should exist between specified switch terminals with switch in specified position. See appropriate POWER WINDOW MAIN SWITCH CONTINUITY TEST table. (Scheme 1) If continuity does not exist between specified terminals, replace power window main switch.

Scheme 1

Scheme 1: POWER WINDOW MAIN SWITCH TEST
Scheme 1: POWER WINDOW MAIN SWITCH TEST
Switch PositionTerminal No.Wire Color
Left Front Switch
Locked & Unlocked
Up1 & 12BLU & BLK/RED
"2 & 7BLU/RED & BLK
Off1, 2 & 7BLU, BLU/RED, BLK
"1 & 7BLU & BLK
Down2 & 12BLU/RED & BLK/RED
"1 & 7BLU & BLK
Right Front Switch
Locked
Up5 & 12BLK/BLU & BLK/RED
Off5 & 6BLK/BLU & RED/GRN
Down6 & 12RED/GRN & BLK/RED
Unlocked
Up5 & 12BLK/BLU & BLK/RED
"6 & 7RED/GRN & BLK
Off5, 6 & 7BLK/BLU, RED/GRN & BLK
Down6 & 12RED/GRN & BLK/RED
"5 & 7BLK/BLU & BLK
Right Rear Switch
Locked
Up12 & 14BLK/RED & BLU/WHT
Off13 & 14GRN/WHT & BLU/WHT
Down12 & 13BLK/RED & GRN/WHT
Unlocked
Up12 & 14BLK/RED & BLU/WHT
"7 & 13BLK & GRN/WHT
Off7, 13 & 14BLK, GRN/WHT & BLU/WHT
Down12 & 13BLK/RED & GRN/WHT
"7 & 14BLK & BLU/WHT
Left Rear Switch
Locked
Up9 & 12GRN/YEL & BLK/RED
Off9 & 10GRN/YEL & GRN/BLK
Down10 & 12GRN/BLK & BLK/RED
Unlocked
Up9 & 12GRN/YEL & BLK/RED
"7 & 10BLK & GRN/BLK
Off7, 9 & 10BLK, GRN/YEL & GRN/BLK
Down10 & 12GRN/BLK & BLK/RED
"7 & 9BLK & GRN/YEL

POWER WINDOW MAIN SWITCH CONTINUITY TEST

Switch PositionTerminal No.Wire Color
Left Front Switch
Locked & Unlocked
Up7 & 8RED & BLU
"12 & 13BLK & BLU/RED
Off8, 12 & 13BLU, BLK & BLU/RED
Down8 & 12BLU & BLK
"7 & 13RED & BLU/RED
Right Front Switch
Locked
Up7 & 14RED & WHT
Off9 & 14WHT/GRY & WHT
Down7 & 9RED & WHT/GRY
Unlocked
Up7 & 14RED & WHT
"9 & 12WHT/GRY & BLK
Off9, 12 & 14WHT/GRY, BLK & WHT
Down12 & 14BLK & WHT
"7 & 9RED & WHT/GRY
Left Rear Switch
Locked
Up5 & 7WHT/RED & RED
Off5 & 10WHT/RED & WHT/YEL
Down7 & 10RED & WHT/YEL
Unlocked
Up5 & 7WHT/RED & RED
"10 & 12WHT/YEL & BLK
Off5, 10 & 12WHT/RED, WHT/YEL & BLK
Down7 & 10RED & WHT/YEL
"5 & 12WHT/RED & BLK
Right Rear Switch
Locked
Up7 & 11RED & WHT/BLU
Off6 & 11BLU/BLK & WHT/BLU
Down6 & 7BLU/BLK & RED
Unlocked
Up7 & 11RED & WHT/BLU
"6 & 12BLU/BLK & BLK
Off6, 11 & 12BLU/BLK, WHT/BLU & BLK
Down6 & 7BLU/BLK & RED
"11 & 12WHT/BLU & BLK

POWER WINDOW MAIN SWITCH CONTINUITY TEST

Switch PositionTerminal No.Wire Color
Left Front Switch
Locked & Unlocked
Up7 & 13BLK/YEL & BLU
"8 & 12BLU/RED & BLK
Off8, 12 & 13BLU/RED, BLK & BLU
Down12 & 13BLK & BLU
"7 & 8BLK/YEL & BLU/RED
Right Front Switch
Locked
Up7 & 14BLK/YEL & RED/BLK
Off9 & 14BLK/BLU & RED/BLK
Down7 & 9BLK/YEL & BLK/BLU
Unlocked
Up7 & 14BLK/YEL & RED/BLK
"9 & 12BLK/BLU & BLK
Off9, 12 & 14BLK/BLU, BLK & RED/BLK
Down12 & 14BLK & RED/BLK
"7 & 9BLK/YEL & BLK/BLU
Left Rear Switch
Locked
Up7 & 10BLK/YEL & GRY/YEL
Off5 & 10GRY/BLK & GRY/YEL
Down5 & 7GRY/BLK & BLK/YEL
Unlocked
Up7 & 10BLK/YEL & GRY/YEL
"5 & 12GRY/BLK & BLK
Off5, 10 & 12GRY/BLK, GRY/YEL & BLK
Down5 & 7GRY/YEL & BLK/YEL
"10 & 12GRY/YEL & BLK
Right Rear Switch
Locked
Up6 & 7BLU/WHT & BLK/YEL
Off6 & 11BLU/WHT & GRY/WHT
Down7 & 11BLK/YEL & GRY/WHT
Unlocked
Up6 & 7BLU/WHT & BLK/YEL
"11 & 12GRY/WHT & BLK
Off6, 11 & 12BLU/WHT, GRY/WHT & BLK
Down7 & 11BLK/YEL & GRY/WHT
"6 & 12BLU/WHT & BLK

POWER WINDOW MAIN SWITCH CONTINUITY TEST

POWER WINDOW SUB-SWITCH TEST

Remove power window sub-switch from door panel. Disconnect harness connector. Continuity should exist between specified switch terminals with switch in specified position. See appropriate POWER WINDOW SUB-SWITCH CONTINUITY TEST table. (Scheme 2)or (Scheme 3). If continuity does not exist between specified terminals, replace power window sub-switch.

Scheme 2

Scheme 2: POWER WINDOW SUB-SWITCH TEST
Scheme 2: POWER WINDOW SUB-SWITCH TEST

Scheme 3

Scheme 3
Scheme 3
Switch PositionTerminals No.Wire Color
Right Front
Up5 & 8BLU & BLK/RED
"4 & 7RED/GRN & BLU/RED
Off5 & 6BLU & BLK/BLU
"4 & 7RED/GRN & BLU/RED
Down7 & 8BLU/RED & BLK/RED
"5 & 6BLU & BLK/BLU
Right Rear
Up5 & 6BLU/RED & BLK/RED
"1 & 4BLU/WHT & BLU
Off2 & 5BLU/WHT & BLU/RED
"1 & 4GRN/WHT & BLU
Down2 & 5BLU/WHT & BLU/RED
"4 & 6BLU & BLK/RED
Left Rear
Up5 & 6BLU/RED & BLK/RED
"1 & 4GRN/WHT & BLU
Off2 & 5BLU/WHT & BLU/RED
"1 & 4GRN/WHT & BLU
Down4 & 5BLU & BLU/RED
"2 & 5BLU/WHT & BLU/RED

POWER WINDOW SUB-SWITCH CONTINUITY TEST

Switch PositionTerminals No.Wire Color
Right Front
Up3 & 4RED & BLU
"1 & 2BLU/RED & WHT/GRY
Off1 & 2BLU/RED & WHT/GRY
"4 & 5BLU & WHT
Down1 & 3BLU/RED & RED
"4 & 5BLU & WHT
Right & Left Rear
Up3 & 4BLK/BLU & BLU/RED
"1 & 2BLU & GRY/WHT
Off1 & 2BLU & GRY/WHT
"4 & 5BLU/RED & LT GRN
Down1 & 3BLU & BLK/BLU
"4 & 5BLU/RED & LT GRN

POWER WINDOW SUB-SWITCH CONTINUITY TEST

Switch PositionTerminals No.Wire Color
Right Front
Up1 & 4BLK/BLU & BLU/RED
"2 & 5BLU & BLK/YEL
Off1 & 4BLK/BLU & BLU/RED
"2 & 3BLU & RED/BLK
Down2 & 3BLU & RED/BLK
"4 & 5BLU/RED & BLK/YEL
Right Rear
Up2 & 5BLU & BLK/YEL
"3 & 4GRY/WHT & BLU/RED
Off1 & 2BLU/WHT & BLU
"3 & 4GRY/WHT & BLU/RED
Down1 & 2BLU/WHT & BLU
"4 & 5BLU/RED & BLK/YEL
Left Rear
Up2 & 5BLU & BLK/YEL
"3 & 4GRY/BLK & BLU/RED
Off1 & 2GRY/YEL & BLU
"3 & 4GRY/BLK & BLU/RED
Down1 & 2GRY/YEL & BLU
"4 & 5BLU/RED & BLK/YEL

POWER WINDOW SUB-SWITCH CONTINUITY TEST
