Maintenance Information: Overview Subaru Forester SF

Fuse & Circuit Breaker Identification

1. 1 - 15 Amp Heater Fan
2. 2 - 15 Amp Heater Fan
3. 3 - 15 Amp Power Door Lock
4. 4 - 20 Amp Front Accessory Power Socket, Cigarette Lighter, Remote Controlled Rear View Mirrors
5. 5 - 10 Amp Tail Lights, Parking Light
6. 6 - 15 Amp SRS Airbag
7. 7 - 15 Amp Fog Light
8. 8 - 20 Amp ABS Solenoid
9. 9 - 15 Amp Radio, Clock
10. 10 - Not Used
11. 11 - 15 Amp Engine Ignition System, SRS Airbag
12. 12 - 10 Amp Illumination Brightness Control
13. 13 - Not Used
14. 14 - Not Used
15. 15 - 20 Amp Windshield Wiper & Washer, Rear Window Wiper & Washer
16. 16 - 20 Amp Brake Light
17. 17 - 15 Amp Air Conditioner
18. 18 - 15 Amp Back-Up Light, Cruise Control, ABS Control
19. 19 - 20 Amp Rear Accessory Power Socket, Seat Heater

Scheme 1

1. 20 - 20 Amp Radiator Cooling Fan (Main)
2. 21 - 20 Amp Radiator Cooling Fan (Sub)
3. 22 - 20 Amp Rear Window Defogger
4. 23 - 15 Amp Hazard Warning Flasher, Horn
5. 24 - 15 Amp Meter, SRS Airbag Warning Light
6. 25 - 10 Amp Automatic Transmission Control Unit
7. 26 - 10 Amp Alternator
8. 27 - 15 Amp Headlight (Right Side)
9. 28 - 15 Amp Headlight (Left Side)
10. 29 - 20 Amp Lighting Switch
11. 30 - 15 Amp Clock, Interior Light
