BELT ADJUSTMENT
Note. Use illustrations for belt alignment. (Scheme 1)and (Scheme 2).
| Application | Deflection - In. (mm) | |
|---|---|---|
| Impreza | ||
| A/C | .30-.34 (7.5-8.5) | |
| Generator & P/S | .28-.35 (7.0-9.0) | |
| Forester & Legacy | ||
| A/C | .35-.39 (9.0-10.0) | |
| Generator & P/S | .35-.43 (9.0-11.0) | |
| SVX | ||
| A/C | .24-.28 (6.0-7.0) | |
| Generator & P/S | .16-.20 (4.0-5.0) | |
