Starting/charging — Starting circuit, w/o hev & push button start Subaru Crosstrek I facelift
All systems — 32 systems
- Active bodyworks
- Air conditioning 2
- Anti-lock brakes 3
- Anti-theft 4
- Body control modules 2
- Computer data lines 2
- Cooling fan
- Cruise control 2
- Defoggers 2
- Electronic power steering
- Engine performance 2.0l
- Engine performance 2.0l hybrid
- Exterior lights 4
- Ground distribution 2
- Headlights 4
- Horn
- Instrument cluster 2
- Interior lights 4
- Navigation 7
- Power distribution 3
- Power door locks 3
- Power mirrors 4
- Power seats
- Power top/sunroof 2
- Power windows
- Radio 4
- Shift interlock
- Starting/charging 5
- Supplemental restraints 2
- Transmission 2
- Warning systems 3
- Wiper/washer 2
Components on these wiring diagrams 12
Click a component to highlight it on every diagram it appears on.
