Wiring diagram: Navigation — Front view camera circuit Subaru Crosstrek GT facelift
All systems — 34 systems
- Active bodyworks
- Air conditioning 2
- Anti-lock brakes 3
- Anti-theft 4
- Body control modules
- Computer data lines 2
- Cooling fan 2
- Cruise control 2
- Defoggers 4
- Electronic power steering
- Engine performance 2.0l
- Engine performance 2.0l hybrid 2
- Engine performance 2.5l
- Exterior lights 4
- Ground distribution 2
- Headlights 4
- Horn
- Instrument cluster 3
- Interior lights 3
- Navigation 7
- Power distribution 2
- Power door locks 3
- Power mirrors 2
- Power seats 3
- Power top/sunroof
- Power windows
- Radio 5
- Shift interlock 3
- Starting/charging 2
- Supplemental restraints
- Transmission 3
- Trunk, tailgate, fuel door 3
- Warning systems 2
- Wiper/washer 2
Components on these wiring diagrams 9
Click a component to highlight it on every diagram it appears on.
