Mirrors (Exterior): Removal & Installation Subaru BRZ ZC

Removal

Note. The following procedure is for LH side. Perform the same procedures for the RH and LH side.

Scheme 4

Scheme 5

Scheme 6

1. Removal of the door armrest cover LH (Refer to «ASSEMBLY»(ref-619177-S05968310512014053000000) )
2. Removal of the front door trim board sub-assembly LH (Refer to «ASSEMBLY»(ref-619177-S05968310512014053000000) )
3. Removal of the front door service hole cover LH (Refer to «ASSEMBLY»(ref-619177-S05968310512014053000000) )
4. Removal of the outer mirror cover lower LH Retract the outer rear-view mirror LH. Using a flat tip screwdriver that is wrapped in protective tape, release tab < A > from the slit. Release the 4 < B > tabs and remove the outer mirror cover lower LH.
5. Removal of the outer rear-view mirror LH Disconnect the connector. Remove the 3 bolts and remove the outer rear-view mirror LH.

Installation

Note. The following procedure is for LH side. Perform the same procedures for the RH and LH side.

Scheme 7

1. Installation of the outer rear-view mirror LH Retract the outer rear-view mirror LH. Using 3 bolts, install the outer rear view mirror LH. Standard value: T=7.5N.m {76kgf.cm} {5.5ft.lbf} Align the alignment mark of the wiring harness with the harness clip on the body side, and install the wiring harness.
2. Installation of the outer mirror cover lower LH Fit in the 5 tabs and install the outer mirror cover lower LH.
3. Installation of the front door service hole cover LH (Refer to «ADJUSTMENT»(ref-619177-S16580397182014053000000) )
4. Installation of the front door trim board sub-assembly LH (Refer to «ADJUSTMENT»(ref-619177-S16580397182014053000000) )
5. Installation of the door armrest cover LH (Refer to «ADJUSTMENT»(ref-619177-S16580397182014053000000) )

Scheme 8

Scheme 9

1. Inspection of the outer rear-view mirror RH Operation inspection for the mirror surface position Inspect operation when battery voltage is applied between connector terminals. CRITERIA Battery connection Operation direction Battery positive -->3 (MR+) Battery ground -->8 (MV) Upward Battery positive -->8 (MV) Battery ground -->3 (MR+) Downward Battery positive -->3 (MR+) Battery ground -->7 (MH) Rightward Battery positive -->7 (MH) Battery ground -->3 (MR+) Leftward Inspection for the mirror heater (when there is a mirror heater) Measure the resistance according to the following chart. RESISTANCE Inspection terminals (Terminal symbol) Inspection conditions Standard value 4 (+) - 10 (-) 25°C {75°F} 9.6 to 14.4 ohms
2. Inspection of the outer rear-view mirror LH Operation inspection for the mirror surface position Inspect operation when battery voltage is applied between connector terminals. CRITERIA Battery connection Operation direction Battery positive -->3 (ML+) Battery ground -->8 (MV) Upward Battery positive -->8 (MV) Battery ground -->3 (ML+) Downward Battery positive -->3 (ML+) Battery ground -->7 (MH) Rightward Battery positive -->7 (MH) Battery ground -->3 (ML+) Leftward Inspection for the mirror heater (when there is a mirror heater) Measure the resistance according to the following chart. RESISTANCE Inspection terminals (Terminal symbol) Inspection conditions Standard value 4 (+) - 10 (-) 25°C {75°F} 9.6 to 14.4 ohms

Scheme 10

Note. The following procedure is for LH side. Perform the same procedures for the RH and LH side.

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. Removal of the outer mirror LH As shown in the figure, push the outer rear-view mirror LH in the forward folding direction. Push the inside of the mirror surface and face the mirror surface towards the interior of the vehicle. Apply protective tape to the location in the figure. Using a molding remover, release the 2 tabs. CAUTION: Be careful not to pull the outer mirror LH with excessive force, as this may disconnect the actuator mechanism or crack the mirror. When there is no mirror heater: Release the 2 tabs and remove the outer mirror LH. With a mirror heater: Release the 2 tabs. Disconnect the 2 connectors and remove the outer mirror LH.

Note. The following procedure is for LH side. Perform the same procedures for the RH and LH side.

Scheme 16

Scheme 17

1. Installation of the outer mirror LH When there is no mirror heater: Fit in the 2 tabs. With a mirror heater: Connect the 2 connectors. Fit in the 2 tabs. Fit in the 2 tabs and install the outer mirror LH. CAUTION: Be careful not to push the outer rear-view mirror glass with excessive force, as this may crack the mirror. Push the outer rear-view mirror LH in the direction shown in the figure.

Scheme 18

Scheme 19

1. Removal of the door armrest cover LH (Refer to «ASSEMBLY»(ref-619177-S05968310512014053000000) )
2. Removal of the front door trim board sub-assembly LH (Refer to «ASSEMBLY»(ref-619177-S05968310512014053000000) )
3. Removal of the power window regulator master switch assembly W/front armrest base panel upper LH (Refer to «ASSEMBLY»(ref-619177-S05968310512014053000000) )
4. Removal of the outer mirror switch assembly Using a thin flat tip screwdriver wrapped with protective tape, release the 4 tabs and remove the outer mirror switch assembly.

Scheme 20

1. Installation of the outer mirror switch assembly Fit in the 4 tabs and install the outer mirror switch assembly.
2. Installation of the power window regulator master switch assembly W/front armrest base panel upper LH (Refer to «ADJUSTMENT»(ref-619177-S16580397182014053000000) )
3. Installation of the front door trim board sub-assembly LH (Refer to «ADJUSTMENT»(ref-619177-S16580397182014053000000) )
4. Installation of the door armrest cover LH (Refer to «ADJUSTMENT»(ref-619177-S16580397182014053000000) )

Scheme 21

1. Inspection of the outer mirror switch assembly Resistance check Measure the resistance between connector terminals when each switch is operated. Resistance POSITIONING SWITCH (SIDE TO SIDE CHANGING SWITCH, LEFT SIDE) Inspection terminals (Terminal symbol) Inspection conditions Standard value 1 (B) - 14 (ML+) 10 (VL) - 7 (E) Hold down the "Up" switch Less than 1 ohms 1 (B) - 10 (VL) 14 (ML+) - 7 (E) Hold down the "Down" switch Less than 1 ohms 1 (B) - 8 (HL) 14 (ML+) - 7 (E) Hold down the "Left" switch Less than 1 ohms 1 (B) - 14 (ML+) 8 (HL) - 7 (E) Hold down the "Right" switch Less than 1 ohms

Scheme 22

1. Inspection of the MIR HTR relay Measure the resistance between connector terminals. RESISTANCE Inspection terminals Inspection conditions Standard value 3 - 5 When battery voltage is not applied between terminals 1 and 2. 10 kohms or more When battery voltage is applied between terminals 1 and 2. Less than 1 ohms
