Lighting System (Interior): Removal & Installation Subaru BRZ ZC

Removal

Note. The procedures described below are for the RH side. Perform the same procedures for the LH side.

Scheme 30

Scheme 31

Scheme 32

1. Removal of visor ASSY RH Remove the 2 screws. Disconnect the visor ASSY RH from the hook. (Scheme 30): Identifying Visor Mounting (RH) Disconnect the connector and remove the visor ASSY RH. (Scheme 31): Identifying Visor Mounting (LH)
2. Removal of the vanity light lens Release the claws by using a flat tip screwdriver wrapped with protective tape, and remove the vanity light lens. (Scheme 32): Removing Vanity Light Lens
3. Removal of the vanity light bulb Remove the vanity light bulb from the visor ASSY RH.

Installation

Note. The procedures described below are for the RH side. Perform the same procedures for the LH side.

Scheme 33

1. Installation of the vanity light bulb Install the vanity light bulb to the visor ASSY RH.
2. Installation of the vanity light lens Engage the claws and install the vanity light lens. (Scheme 33): Installing Vanity Light Lens
3. Installation of visor ASSY RH Connect the connector. Place the visor ASSY RH on the hook. With the 2 screws, install the visor ASSY RH.

Scheme 34

1. Inspection of the visor ASSY RH Measure the resistance between the connector terminals when the visor ASSY RH (vanity light switch) is operated. Resistance Inspection terminals Inspection conditions Standard value 1 - 2 Mirror cover closed 10 kohms or more 1 - 2 Mirror cover opened Less than 1 ohms (Scheme 34): Identifying Visor Assembly Connector

Exploded View Of Map Light Assembly. Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

1. Removal of the map light ASSY Release the 2 tabs. (Scheme 36): Identifying Map Light Assembly Tabs Release two guides and disconnect the map light ASSY. (Scheme 37): Disconnecting Map Light Assembly Disconnect the connector and remove the map light ASSY. (Scheme 38): Map Light Assembly Connector
2. Removal of the map light lens NO.1 Release two claws by using a fine flat tip screwdriver wrapped with protective tape, and remove the map light lens NO.1. (Scheme 39): Removing Map Light Lens No.1
3. Removal of the map light bulb Remove the map light bulb.

1. Installation of the map light bulb Install the map light bulb.
2. Installation of the map light lens NO.1 Engage two claws and install the map light lens NO.1.
3. Installation of the map light ASSY Connect the connector. Insert two guides. Engage two claws and install the map light ASSY.

Scheme 40

1. Inspection of the map light ASSY Illumination condition check for the map light Check the illumination condition of the map light when battery voltage is applied between the connector terminals. Criteria Battery connection Inspection conditions Criteria Battery positive terminal -->2(+B) Battery ground terminal -->1 (GND) Map light switch ON The map light illuminates. Battery positive terminal -->2(+B) Battery ground terminal -->3 (DOOR SW) Map light switch DOOR The map light illuminates. (Scheme 40): Identifying Map Light Assembly Harness Connector

Exploded View Of Trunk Room Light. Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

1. Removal of the trunk light ASSY NO.1 Rotate the trunk light ASSY NO.1 as shown in the figure, and disconnect the trunk light ASSY NO.1 from the vehicle. (Scheme 42): Removing Trunk Light Assembly No. 1 Disconnect the connector and remove the trunk light ASSY NO.1. (Scheme 43): Identifying Trunk Light Assembly No. 1 Connector
2. Removal of the trunk light lens Release two claws and remove the trunk light lens. (Scheme 44): Removing Trunk Light Lens
3. Removal of the trunk bulb Remove the trunk light valve. (Scheme 45): Identifying Bulb

Scheme 46

1. Installation of the trunk light bulb Install the trunk light valve.
2. Installation of the trunk light lens Engage two claws and install the trunk light lens.
3. Installation of the trunk light ASSY NO.1 Connect the connector. Rotate the trunk light ASSY NO.1 as shown in the figure, and install the trunk light ASSY NO.1. (Scheme 46): Installing Trunk Light Assembly No. 1

Scheme 47

1. Inspection of the trunk light ASSY NO.1 Check the illumination condition when battery voltage is applied between the connector terminals. Criteria Inspection terminals Inspection conditions Criteria 1 - 2 Battery positive -->1 Battery ground -->2 Light turns on. (Scheme 47): Trunk Light Assemnly No. 1 Harness Connector NOTE: Perform the inspection using a properly functioning bulb.

Exploded View Of Door Courtesy Light. Scheme 48

Note. The procedures described below are for the RH side. Perform the same procedures for the LH side.

Scheme 49

Scheme 50

Scheme 51

Scheme 52

1. Removal of the courtesy light ASSY Using a flat head screw driver wrapped in protective tape, release the tab. (Scheme 49): Removing Door Courtesy Light Disconnect the connector and remove the courtesy light ASSY. (Scheme 50): Door Courtesy Light Connector
2. Removal of the courtesy light bulb Release the claws by using a flat tip screwdriver wrapped with protective tape, and remove the courtesy light cover. (Scheme 51): Removing Courtesy Light Cover Remove the courtesy light bulb. (Scheme 52): Courtesy Light Bulb

Note. The procedures described below are for the RH side. Perform the same procedures for the LH side.

Scheme 53

1. Installation of the courtesy light bulb Install the courtesy light bulb. Engage the claws and install the courtesy light cover.
2. Installation of the courtesy light ASSY Connect the connector. Engage the claws and install the courtesy light ASSY. (Scheme 53): Installing Courtesy Light

1. Installation of the transponder key amplifier Engage two claws and install the transponder key amplifier. Connect the connector.
2. Installation of the steering column cover UPR (Refer to «INSTALLATION»(ref-619170-S08739488282014053000000) )
3. Installation of the steering column cover LWR (Refer to «INSTALLATION»(ref-619170-S08739488282014053000000) )

Scheme 54

1. Inspection of the transponder key amplifier Light inspection Inspect if the light turns on when battery voltage is applied to each connector terminal. Criteria Battery connection Criteria Battery positive terminal -->2 (ILL+) Battery ground terminal -->6 (ILL-) Light turns on. (Scheme 54): Transponder Key Amplifier Harness Connector

Exploded View Of Front Door Courtesy Switch. Scheme 55

Note. The following procedure is for LH side. Perform the same procedures for the RH side.

Scheme 56

Scheme 57

1. Removal of the front door courtesy light switch ASSY Remove the bolt. (Scheme 56): Locating Front Door Courtesy Light Switch Disconnect the connector and remove the front door courtesy light switch ASSY. (Scheme 57): Front Door Courtesy Light Switch Connector

1. Installation of the front door courtesy light switch ASSY Connect the connector. Install the front door courtesy light switch ASSY with the bolt. Standard value: T=7.5N.m {77kgf.cm} {5.5ft.lbf}

Scheme 58

1. Inspection of the front door courtesy light switch ASSY Measure the resistance when the shaft of the front door courtesy light switch ASSY is operated. Resistance Inspection terminals Inspection conditions Standard value 1 - Chassis ground When the shaft is not pushed in Less than 1 ohms 1 - Chassis ground When the shaft is pushed in 10 kohms or more (Scheme 58): Front Door Courtesy Light Switch Harness Connector
