Legend of wiring diagram for heated rear window - PE67.29-P-2000-60MCU
| Code | Designation | Coordinates |
|---|
| N10/10 | SAM control unit | 4A |
| N10/10 | SAM control unit | 11A |
| N10/10f28 | Fuse 28 | 3A |
| N10/10f28 | Fuse 28 | 7A |
| N23 | Heater/AC operating unit | 13L |
| N23s1 | Heated rear window switch | 15L |
| R1 | Rear window defroster | 3L |
| R1 | Rear window defroster | 8L |
| U23 | Valid for convertibles | 6A |
| U606 | Valid for all except convertibles | 1A |
| W6 | Ground (left wheel well in luggage compartment) | 5H |
| W6 | Ground (left wheel well in luggage compartment) | 10H |
| X18/19 | Trunk lid connector | 2E |
| X23/7 | Soft top connector | 6E |
| X23/7 | Soft top connector | 8E |
| Z6/16 | Soft top ground connector sleeve | 8H |
| Z6/20 | Trunk lid ground connector sleeve | 3H |
Electric wiring diagram for heated rear window - PE67.29-P-2000MCU
| PE67.29-P-2000-99MCU | Electric wiring diagram for heated rear window | | PE67.29-P-2000-99MCU |
|---|
| PE67.29-P-2000-60MCU | Legend of wiring diagram for heated rear window | | PE67.29-P-2000-60MCU |
| OV00.01-P-1901-03MCC | Use of wiring diagrams | | OV00.01-P-1901-03MCC |
| OV00.01-P-1901MCU | Search aid for all wiring diagram groups | | OV00.01-P-1901MCU |
| OV00.01-P-1001-27MC | Abbreviations for wiring diagrams | | OV00.01-P-1001-27MC |
| OV00.01-P-1001-28MC | Abbreviations of signal and circuit designations for wiring diagrams | | OV00.01-P-1001-28MC |
| GF00.19-P-1000MCU | Location and assignment of line and connectors | | GF00.19-P-1000MCU |
| GF00.19-P-2000MCU | Location and assignment of ground points | | GF00.19-P-2000MCU |
| GF00.19-P-3000MCU | Location and assignment of Z connector sleeves (line connectors in wiring harness) | | GF00.19-P-3000MCU |
| PE54.00-P-1100MCU | | Further wiring diagrams | PE54.00-P-1100MCU |
| PE83.00-P-1100MCU | | Further wiring diagrams | PE83.00-P-1100MCU |
Electric wiring diagram for heated rear window - PE67.29-P-2000-99MCU
| Code | Designation | Position |
|---|
| N10/10 | SAM control unit | 4 A |
| N10/10 | SAM control unit | 11 A |
| N10/10f28 | Fuse 28 | 2 A |
| N10/10f28 | Fuse 28 | 7 A |
| N23 | Heater/AC operating unit | 13 L |
| N23s1 | Rear window defroster switch | 14 L |
| R1 | Heated rear window | 3 L |
| R1 | Heated rear window | 8 L |
| U23 | Valid for cabriolet | 6 A |
| U606 | Valid for all except convertibles | 1 A |
| W6 | Ground (left wheelhousing in trunk) | 5 H |
| W6 | Ground (left wheelhousing in trunk) | 9 H |
| X18/19 | Trunk lid connector | 2 E |
| X23/7 | Soft top connector | 6 E |
| X23/7 | Soft top connector | 8 E |
| Z6/16 | Soft top ground connector sleeve | 8 H |
| Z6/20 | Trunk lid ground connector sleeve | 3 H |
Scheme 19
| PE67.29-P-2000-99MCU | Electric wiring diagram for heated rear window | | PE67.29-P-2000-99MCU |
|---|
| PE67.29-P-2000-60MCU | Legend of wiring diagram for heated rear window | | PE67.29-P-2000-60MCU |
| OV00.01-P-1901-03MCC | Use of wiring diagrams | | OV00.01-P-1901-03MCC |
| OV00.01-P-1901MCU | Search aid for all wiring diagram groups | | OV00.01-P-1901MCU |
| OV00.01-P-1001-27MC | Abbreviations for wiring diagrams | | OV00.01-P-1001-27MC |
| OV00.01-P-1001-28MC | Abbreviations of signal and circuit designations for wiring diagrams | | OV00.01-P-1001-28MC |
| GF00.19-P-1000MCU | Location and assignment of line and connectors | | GF00.19-P-1000MCU |
| GF00.19-P-2000MCU | Location and assignment of ground points | | GF00.19-P-2000MCU |
| GF00.19-P-3000MCU | Location and assignment of Z connector sleeves (line connectors in wiring harness) | | GF00.19-P-3000MCU |
| PE54.00-P-1100MCU | | Further wiring diagrams | PE54.00-P-1100MCU |
| PE83.00-P-1100MCU | | Further wiring diagrams | PE83.00-P-1100MCU |
