Engine Cooling System (Coupe): Adjustments Smart Fortwo II

Cooling System (Mechanical) 10 illustrations ~297 words

Engine cooling system - check fluid level, adjust to correct level. Inspect anticorrosion/antifreeze protection, adjust to correct concentration - AP20.00-P-2010MCU

ENGINE 132.910 in MODEL 451.3 /4

Scheme 4

Scheme 4: Engine cooling system - check fluid level, adjust to correct level. Inspect anticorrosion/antifreeze
Scheme 4: Engine cooling system - check fluid level, adjust to correct level. Inspect anticorrosion/antifreeze

Removal Risk of injury to skin and eyes caused by scalding from contact with hot coolant spray. Risk of poisoning caused by swallowing coolant. Do not open cooling system unless coolant temperature is below 90°C. Open cap slowly and release the pressure. Do not pour coolant into beverage containers. Wear protective gloves, protective clothing and safety glasses. AS20.00-Z-0001-01A 1 Remove maintenance flap (3) 2 Turn cooling system cap (1) on the engine radiator (2) a half turn counterclockwise, relieve the pressure and then unscrew the cooling system cap (1) Check 3 Check corrosion/antifreeze in coolant and enter in the maintenance sheet see scheme 2 Coolant specifications Sheet 310.1 BB00.40-P-0310-01A Anticorrosion/antifreeze agents (Sheet 325.0) Sheet 325.0 BB00.40-P-0325-00A If necessary:↓ Correct the coolant composition - subject to separate repair order. Replace coolant AP20.00-P-2080MCU Notes on coolant AH20.00-N-2080-01A 4 Check coolant level in the expansion reservoir (2) and correct if necessary The engine coolant level at the coolant expansion reservoir (2) must be positioned at the max. marking. Coolant specifications Sheet 310.1 BB00.40-P-0310-01A Anticorrosion/antifreeze agents (Sheet 325.0) Sheet 325.0 BB00.40-P-0325-00A In the event of a fluid loss not caused by consumption or if the coolant circuit has been opened, the cooling system must be checked for leaks - subject to separate repair order. Inspecting cooling system for leaks AR20.00-P-1010MCU Notes on coolant AH20.00-N-2080-01A Install 5 Seal expansion reservoir (2) with cap (1) 6 Install maintenance flap (3)

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Test and adjustment values: Smart: Engine cooling system - BE20.00-Z-9999CZ

MODEL all

Test values for cooling system capENGINE allBE20.30-P-1000-01A
