Lighting (Diagnostics): Other Scion xD I

Exterior Lights 5 illustrations ~402 words

PRECAUTION

PRECAUTION FOR HEADLIGHT BULB REPLACEMENT (HALOGEN BULB) Halogen bulbs have pressurized gas inside and require special handling. They can shatter if scratched or dropped. Hold the bulb only by its plastic or metal case. Do not touch the glass part of a bulb with bare hands.

Scheme 176: ILLUSTRATION

Scheme 177: ILLUSTRATION

Scheme 178: ILLUSTRATION

Scheme 179: SYSTEM DIAGRAM

CUSTOMIZING FUNCTION WITH TECHSTREAM HINT: The following items can be customized. NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Be sure to make a note of the current settings before customizing. When troubleshooting a function, first make sure that the function is set to the default setting. Connect a Techstream to the DLC3. Turn the ignition switch to ON. Turn the tester on. Enter the following menus: Customize Setting / Select the setting by referring to the table below. MAIN BODY (MAIN BODY ECU) Display Default Contents Setting Lighting Time 15 seconds Changes illumination duration after door closure. (It will quickly fade out when turning the ignition switch ON.) 7.5/ 15/ 30 (seconds) I/L ON / ACC OFF ON Illuminates light when ignition switch turned to ACC (Room light illuminated when interior light switch set to DOOR) ON / OFF I/L ON / Unlock ON Function to light up room light when unlocking with door key cylinder (Room light illuminated when interior light switch set to DOOR) ON / OFF

READ VALUE USING TECHSTREAM (DOOR LOCK POS SW) Connect a Techstream to the DLC3. Turn the ignition switch to ON. Turn the tester on. Select the following menus: Body Electrical / Main Body / Data List / According to the display on tester, read the "Data List". MAIN BODY (MAIN BODY ECU) Tester Display Measurement Item/Range Normal Condition Diagnostic Note D-Door Lock Pos SW Driver side door lock position switch signal / ON or OFF ON: Driver side door unlocked OFF: Driver side door locked - P-Door Lock Pos SW Front passenger side door lock position switch signal / ON or OFF ON: Front passenger side door unlocked OFF: Front passenger side locked - OK Normal conditions listed above are displayed. NG --> See step 3 OK --> See step 2
PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-388783-S23384175322011031100000)
GO TO POWER DOOR LOCK CONTROL SYSTEM. Refer to «PROBLEM SYMPTOMS TABLE»(ref-388806-S17631247572011031100000)
