Windshield / Windowglass (Service Information): Overview Scion xB II рестайлинг

Scheme 23

Scheme 24

1. REMOVE FRONT ARMREST BASE UPPER PANEL LH HINT: Use the same procedure as for the RH side. Refer to «DISASSEMBLY - Step 2»(ref-511410-S19523977452012102600000) .
2. REMOVE POWER WINDOW MASTER SWITCH Remove the 3 screws and the power window master switch.

Scheme 25

1. INSPECT POWER WINDOW MASTER SWITCH Check the resistance. Measure the resistance according to the value(s) in the table below. Standard resistance Driver switch Tester Connection Window Lock Switch Condition Power Window Switch Condition Specified Condition 3 (U) - 6 (B) 1 (E) - 4 (D) Always (ON / OFF) UP Below 1 ohms 1 (E) - 3 (U) 1 (E) - 4 (D) Always (ON / OFF) OFF Below 1 ohms 4 (D) - 6 (B) 1 (E) - 3 (U) Always (ON / OFF) DOWN MANUAL Below 1 ohms 1 (E) - 3 (U) 4 (D) - 6 (B) Always (ON / OFF) DOWN AUTO Below 1 ohms If the result is not as specified, replace the power window master switch. Standard resistance Front passenger side switch Tester Connection Window Lock Switch Condition Power Window Switch Condition Specified Condition 6 (B) - 16 (U) 1 (E) - 15 (D) OFF UP Below 1 ohms 1 (E) - 16 (U) 1 (E) - 15 (D) OFF OFF Below 1 ohms 6 (B) - 15 (D) 1 (E) - 16 (U) OFF DOWN Below 1 ohms 6 (B) - 16 (U) ON UP Below 1 ohms 1 (E) - 15 (D) ON UP 10 kohms or higher 15 (D) - 16 (U) ON OFF Below 1 ohms 6 (B) - 15 (D) ON DOWN Below 1 ohms 1 (E) - 15 (D) ON DOWN 10 kohms or higher If the result is not as specified, replace the power window master switch. Standard resistance Rear LH side switch Tester Connection Window Lock Switch Condition Power Window Switch Condition Specified Condition 6 (B) - 12 (U) 1 (E) - 13 (D) OFF UP Below 1 ohms 1 (E) - 12 (U) 1 (E) - 13 (D) OFF OFF Below 1 ohms 6 (B) - 13 (D) 1 (E) - 12 (U) OFF DOWN Below 1 ohms 6 (B) - 12 (U) ON UP Below 1 ohms 1 (E) - 13 (D) ON UP 10 kohms or higher 12 (U) - 13 (D) ON OFF Below 1 ohms 6 (B) - 13 (D) ON DOWN Below 1 ohms 1 (E) - 12 (U) ON DOWN 10 kohms or higher If the result is not as specified, replace the power window master switch. Standard resistance Rear RH side switch Tester Connection Window Lock Switch Condition Power Window Switch Condition Specified Condition 6 (B) - 10 (U) 1 (E) - 18 (D) OFF UP Below 1 ohms 1 (E) - 10 (U) 1 (E) - 18 (D) OFF OFF Below 1 ohms 6 (B) - 18 (D) 1 (E) - 10 (U) OFF DOWN Below 1 ohms 6 (B) - 10 (U) ON UP Below 1 ohms 1 (E) - 18 (D) ON UP 10 kohms or higher 10 (U) - 18 (D) ON OFF Below 1 ohms 6 (B) - 18 (D) ON DOWN Below 1 ohms 1 (E) - 10 (U) ON DOWN 10 kohms or higher If the result is not as specified, replace the power window master switch. Check the illumination operation. Apply battery voltage to the power window master switch and check that the illumination comes on. OK Measurement Condition Specified Condition Battery positive (+) --> Terminal 6 (B) Battery negative (-) --> Terminal 1 (E) Illumination come on If the result is not as specified, replace the power window master switch.
