Wiring diagram: Wiper/washer — Front wiper/washer circuit Scion xB I
All systems — 24 systems
- Air conditioning
- Anti-lock brakes
- Computer data lines
- Cooling fan
- Defoggers
- Engine performance 1.5l
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster
- Interior lights 2
- Power distribution
- Power door locks
- Power mirrors
- Power windows
- Radio
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer 2
Components on these wiring diagrams 5
Click a component to highlight it on every diagram it appears on.
