Front Bumper Scion xA I

Exterior/interior Trim 6 illustrations ~334 words

Scheme 96

Scheme 96: COMPONENTS
Scheme 96: COMPONENTS

REPLACEMENT

Note. The installation procedures are the removal procedures in reverse order. However, only installation procedures requiring additional information are included.

Scheme 97

Scheme 97: REPLACEMENT
Scheme 97: REPLACEMENT

Scheme 98

Scheme 98
Scheme 98

Scheme 99

Scheme 99
Scheme 99

Scheme 100

Scheme 100
Scheme 100

Scheme 101

Scheme 101
Scheme 101
  1. REMOVE RADIATOR GRILLE Disengage the 2 claws and remove the 4 clips and radiator grille.
  2. REMOVE FRONT SPOILER PAD LH Remove the 3 screws and spoiler pad.
  3. REMOVE FRONT SPOILER PAD RH Remove the 3 screws and spoiler pad.
  4. REMOVE FRONT BUMPER COVER Put protective tape under the front fender. w/ Fog lamp: Disconnect the fog lamp connectors. Remove the 2 bolts, 8 screws and 3 clips. Using a screwdriver, disengage the 6 claws and remove the bumper cover. NOTE: Tape the screwdriver tip before use.
  5. REMOVE FRONT BUMPER HOLE COVER Using a screwdriver, disengage the 2 claws and remove the hole cover. NOTE: Tape the screwdriver tip before use.
  6. REMOVE FOG LAMP COVER LH (W/O FOG LAMP) Using a screwdriver, disengage the 3 claws and remove the fog lamp cover. NOTE: Tape the screwdriver tip before use.
  7. REMOVE FOG LAMP COVER RH (W/O FOG LAMP) NOTE: Use the same procedures for the RH side and LH side.
  8. REMOVE FOG LAMP ASSY LH (W/ FOG LAMP) Remove the nut and fog lamp.
  9. REMOVE FOG LAMP ASSY RH (W/ FOG LAMP) Remove the nut and fog lamp.
  10. REMOVE SIDE MARKER LAMP ASSY LH Remove the 2 nuts and marker lamp.
  11. REMOVE SIDE MARKER LAMP ASSY RH Remove the 2 nuts and marker lamp.
  12. REMOVE RADIATOR GRILLE LOWER Using a screwdriver, disengage the 13 claws and remove the grille.
  13. REMOVE FRONT LICENCE PLATE MOUNTING BRACKET Remove the 2 screws and mounting bracket.
  14. REMOVE FRONT BUMPER SIDE SUPPORT LH Remove the 2 screws and side support.
  15. REMOVE FRONT BUMPER SIDE SUPPORT RH Remove the 2 screws and side support.
  16. REMOVE FRONT BUMPER ENERGY ABSORBER
  17. REMOVE FRONT BUMPER REINFORCEMENT Remove the 4 nuts and reinforcement.
  18. INSTALL FRONT BUMPER REINFORCEMENT Install the reinforcement with the 4 nuts. Torque: 20 N.m (204 kgf.cm, 15 ft.lbf)
