Wiper System / Washer System (Diagnostics & Circuit Tests): Overview Scion tC II рестайлинг

DESCRIPTION

When the volume of washer fluid decreases to below a certain level (when the level warning switch is turned on), the combination meter warns the driver through illumination of the washer level warning light.

Scheme 97

Scheme 98

1. READ VALUE USING TECHSTREAM (LEVEL WARNING SWITCH) Use the Data List to check if the level warning switch is functioning properly. Refer to «DATA LIST / ACTIVE TEST [05/2013 - ]»(ref-615349-S00807021412014050900000) . COMBINATION METER Tester Display Measurement Item/Range Normal Condition Diagnostic Note Washer Switch Level warning switch / ON or OFF ON: Washer jar and tank empty OFF: Washer jar and tank full - OK On the Techstream screen, item changes between ON and OFF according to the above chart. NG --> See step 3 OK: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (WASHER LEVEL WARNING LIGHT) Operate the Techstream according to the display and select Active Test. Refer to «DATA LIST / ACTIVE TEST [05/2013 - ]»(ref-615349-S00807021412014050900000) . COMBINATION METER Tester Display Test Part Control Range Diagnostic Note Indicat. Lamp Washer Washer level warning light ON/OFF - OK Washer level warning light condition can be switched by Active Test. NG --> See step 5 OK: Go to next step
3. INSPECT LEVEL WARNING SWITCH ASSEMBLY Remove the level warning switch. Refer to «REMOVAL [05/2013 - ]»(ref-615279-S41819563762014050900000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (S) - 2 (E) Fluid volume is more than 900 cc (54.9 cu.in.) 10 kohms or higher 1 (S) - 2 (E) Fluid volume is less than 500 cc (30.5 cu.in.) Below 1 ohms HINT: When the fluid volume is between 500 and 900 cc (30.5 and 54.9 cu.in.), the level warning switch may be on or off. NG --> See step 6 OK: Go to next step
4. CHECK HARNESS AND CONNECTOR (LEVEL WARNING SWITCH ASSEMBLY - COMBINATION METER ASSEMBLY AND BODY GROUND) Disconnect the A17 level warning switch connector. Disconnect the C50 combination meter connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A17-1 (S) - C50-15 (WLVL) Always Below 1 ohms A17-2 (E) - Body ground Always Below 1 ohms A17-1 (S) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 5
5. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE [05/2013 - 01/2014]»(ref-615349-S36773076442014050900000)
6. REPLACE LEVEL WARNING SWITCH ASSEMBLY. Refer to «REMOVAL [05/2013 - ]»(ref-615279-S41819563762014050900000)

When the volume of washer fluid decreases to below a certain level (when the level warning switch is turned on), the combination meter warns the driver through illumination of the washer level warning light.
