Starting System (Service Information): Removal & Installation Scion tC II рестайлинг

INSTALLATION [01/2014 - ]

1. INSTALL STARTER ASSEMBLY Install the starter assembly with the 2 bolts. Torque: 37 N*m (377 kgf*cm, 27 ft.*lbf) Connect the starter connector. Connect the starter wire with the nut. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf) Close the terminal cap.
2. INSTALL BATTERY CARRIER Install the battery carrier with the 4 bolts. Torque: 19 N*m (189 kgf*cm, 14 ft.*lbf)
3. INSTALL BATTERY TRAY
4. INSTALL BATTERY
5. INSTALL BATTERY INSULATOR
6. INSTALL BATTERY CLAMP Attach the hook of the battery clamp to the front battery bracket. Partially tighten the nut and temporarily install the bolt. Adjust the battery clamp position. Tighten the nut and bolt. for bolt Torque: 17 N*m (168 kgf*cm, 12 ft.*lbf) for nut Torque: 3.5 N*m (36 kgf*cm, 31 in.*lbf) TEXT IN ILLUSTRATION *1 Bolt *2 Nut
7. CONNECT CABLE TO POSITIVE BATTERY TERMINAL
8. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [01/2014 - ]»(ref-615109-S31931454042014050900000) .

Scheme 87

Scheme 88

Scheme 89

1. REMOVE CENTER INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY . Refer to «REMOVAL [05/2013 - 01/2014] - Step 5»(ref-615283-S34339847082014050900000)
2. REMOVE ENGINE SWITCH Detach the 5 claws. Disconnect the connector and remove the No. 1 switch hole base. Detach the 2 claws and remove the engine switch.

Scheme 90

Scheme 91

1. INSPECT ENGINE SWITCH Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 7 (SS1) - 5 (GND) Not pushed 10 kohms or higher 2 (SS2) - 5 (GND) Not pushed 10 kohms or higher 7 (SS1) - 5 (GND) Pushed Below 1 ohms 2 (SS2) - 5 (GND) Pushed Below 1 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Engine Switch) If the result is not as specified, replace the engine switch assembly. Apply battery voltage between the terminals of the switch and check the illumination of the switch. TEXT IN ILLUSTRATION *1 Indicator Light - - *a Component without harness connected (Engine Switch) - - OK Measurement Condition Specified Condition Battery positive (+) --> Terminal 11 (SWIL) Battery negative (-) --> Terminal 5 (GND) Illuminates (illumination of lettering) Battery positive (+) --> Terminal 12 (INDS) Battery negative (-) --> Terminal 5 (GND) Illuminates (green) Battery positive (+) --> Terminal 13 (INDW) Battery negative (-) --> Terminal 5 (GND) Illuminates (amber) NOTE: If the positive (+) lead and the negative (-) lead are incorrectly connected, the engine switch indicator will not illuminate. If the voltage is too low, the indicator will not illuminate. If the result is not as specified, replace the engine switch assembly.

INSTALLATION [05/2013 - ]

1. INSTALL ENGINE SWITCH Attach the 2 claws to install the engine switch. Connect the connector. Attach the 5 claws to install the No. 1 switch hole base.
2. INSTALL CENTER INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY . Refer to «INSTALLATION [05/2013 - 01/2014] - Step 12»(ref-615283-S11838403852014050900000)

Scheme 92

Scheme 93

Scheme 94

1. REMOVE LOWER STEERING COLUMN COVER
2. REMOVE IGNITION SWITCH ASSEMBLY Disconnect the ignition switch connector. for Automatic Transaxle: Detach the clamp and disconnect the key interlock solenoid wire harness connector from the ignition switch connector. Remove the 2 screws and ignition switch.

Scheme 95

1. INSPECT IGNITION SWITCH ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition All combinations of all terminals LOCK 10 kohms or higher 2 (AM1) - 3 (ACC) ACC Below 1 ohms 2 (AM1) - 3 (ACC) 2 (AM1) - 4 (IG1) 6 (IG2) - 7 (AM2) ON Below 1 ohms 1 (ST1) - 2 (AM1) 1 (ST1) - 4 (IG1) 6 (IG2) - 7 (AM2) 6 (IG2) - 8 (ST2) START Below 1 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Ignition Switch) If the result is not as specified, replace the ignition switch assembly.

1. INSTALL IGNITION SWITCH ASSEMBLY Install the ignition switch with the 2 screws. for Automatic Transaxle: Attach the clamp to connect the key interlock solenoid wire harness connector to the ignition switch connector. Connect the ignition switch connector.
2. INSTALL LOWER STEERING COLUMN COVER

Scheme 96

1. INSPECT STARTER RELAY (ST) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 Battery voltage not applied to terminals 1 and 2 10 kohms or higher Battery voltage applied to terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the starter relay.
