Engine Cooling System (Service Information): Overview Scion tC II рестайлинг

Scheme 1

1. REMOVE CENTER ENGINE UNDER COVER . Refer to «REMOVAL [05/2013 - 01/2014] - Step 6»(ref-615223-S23575347322014050900000)
2. REMOVE ENGINE UNDER COVER . Refer to «REMOVAL [05/2013 - 01/2014] - Step 7»(ref-615223-S23575347322014050900000)
3. DRAIN COOLANT Install a vinyl hose to the drain cock plug on the radiator side. Loosen the radiator drain cock plug and drain the coolant. TEXT IN ILLUSTRATION *1 Radiator Reservoir *2 Radiator Reservoir Cap *3 Radiator Drain Cock Plug - - HINT: Collect the coolant in a container and dispose of it according to the regulations in your area. Remove the radiator reservoir cap. WARNING: Do not remove the radiator reservoir cap while the engine and radiator are still hot. Pressurized, hot engine coolant and steam may be released and cause serious burns.
4. ADD ENGINE COOLANT Tighten the radiator drain cock plug by hand. Add TOYOTA Super Long Life Coolant (SLLC) to the radiator reservoir filler opening until it is filled to the B line at the base of the reservoir filler neck. HINT: The B line is the lower edge of the inner wall of the filler neck. Standard Capacity Item Specified Condition Manual Transaxle 5.8 liters (6.1 US qts, 5.1 Imp. qts) Automatic Transaxle 5.7 liters (6.0 US qts, 5.0 Imp. qts) HINT: TOYOTA vehicles are filled with TOYOTA SLLC at the factory. In order to avoid damage to the engine cooling system and other technical problems, only use TOYOTA SLLC or similar high quality ethylene glycol based non-silicate, non-amine, non-nitrite, non-borate coolant with long-life hybrid organic acid technology (coolant with long-life hybrid organic acid technology consists of a combination of low phosphates and organic acids). NOTE: Never use water as a substitute for engine coolant. Press the No. 1 and No. 2 radiator hoses several times by hand, and then check the level of the coolant. If the coolant level drops below the B line, add TOYOTA SLLC to the B line. Install the radiator reservoir cap. Start the engine and warm it up until the cooling fan operates. Maintain the engine speed at 2000 to 2500 rpm and warm up the engine until the cooling fan operates. NOTE: Make sure that the radiator reservoir still has some coolant in it. Pay attention to the needle of the coolant temperature meter. Make sure that the needle does not show an abnormally high temperature. If there is not enough coolant, the engine may burn out or overheat. After starting the engine, if the radiator reservoir does not have any coolant, perform the following: 1) stop the engine, 2) wait until the coolant has cooled down, and 3) add coolant until the coolant is filled to the B line. Run the engine at 2000 rpm until the coolant level has stabilized. Press the No. 1 and No. 2 radiator hoses several times by hand to bleed air. WARNING: When pressing the radiator hoses: Wear protective gloves. Be careful as the radiator hoses are hot. Keep your hands away from the radiator fan. Stop the engine and wait until the coolant cools down to ambient temperature. Check that the coolant level is between the FULL and LOW line. If the coolant level is below the LOW line, repeat all of the procedures above. If the coolant level is above the FULL line, drain coolant so that the coolant level is between the FULL and LOW line.
5. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION [05/2013 - ] - Step 1»(ref-615226-S10394305732014050900000)
6. INSTALL ENGINE UNDER COVER . Refer to «INSTALLATION [05/2013 - 01/2014] - Step 82»(ref-615223-S39226060902014050900000)
7. INSTALL CENTER ENGINE UNDER COVER . Refer to «INSTALLATION [05/2013 - 01/2014] - Step 83»(ref-615223-S39226060902014050900000)

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

1. REMOVE RADIATOR SUPPORT CUSHION . Refer to «REMOVAL [05/2013 - ] - Step 1»(ref-615281-S10471054342014050900000)
2. REMOVE RADIATOR SUPPORT OPENING COVER . Refer to «REMOVAL [05/2013 - ] - Step 2»(ref-615281-S10471054342014050900000)
3. REMOVE CENTER ENGINE UNDER COVER . Refer to «REMOVAL [05/2013 - 01/2014] - Step 6»(ref-615223-S23575347322014050900000)
4. REMOVE ENGINE UNDER COVER . Refer to «REMOVAL [05/2013 - 01/2014] - Step 7»(ref-615223-S23575347322014050900000)
5. REMOVE REAR ENGINE UNDER COVER RH . Refer to «REMOVAL [05/2013 - ] - Step 2»(ref-615223-S23019546772014050900000)
6. DRAIN ENGINE COOLANT See step 3
7. REMOVE RADIATOR RESERVOIR Slide the 2 hose clamps and disconnect the No. 1 and No. 2 water by-pass hoses from the radiator reservoir. Remove the 2 bolts and radiator reservoir.
8. REMOVE GENERATOR ASSEMBLY Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615271-S42574237252014050900000)
9. REMOVE V-RIBBED BELT TENSIONER ASSEMBLY Remove the bolt and V-ribbed belt tensioner assembly.
10. REMOVE ENGINE WATER PUMP ASSEMBLY Detach the clamp to disconnect the wire harness from the wire harness bracket. Remove the bolt and wire harness bracket. Remove the 7 bolts, engine water pump assembly and gasket.
