DESCRIPTION
This DTC is stored when LIN communication between the sliding roof drive gear sub-assembly and main body ECU (multiplex network body ECU) stops for 10 seconds or more.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|
| B1273 | No communication between the sliding roof drive gear sub-assembly (sliding roof ECU) and main body ECU (multiplex network body ECU) for 10 seconds or more. | Sliding roof drive gear sub-assembly (sliding roof ECU) Main body ECU (multiplex network body ECU) Instrument panel junction block assembly Harness or connector |
Scheme 43
Scheme 43: WIRING DIAGRAM
This DTC is stored when LIN communication between the sliding roof drive gear sub-assembly and main body ECU (multiplex network body ECU) stops for 10 seconds or more.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|
| B1273 | No communication between the sliding roof drive gear sub-assembly (sliding roof ECU) and main body ECU (multiplex network body ECU) for 10 seconds or more. | Sliding roof drive gear sub-assembly (sliding roof ECU) Main body ECU (multiplex network body ECU) Instrument panel junction block assembly Harness or connector |
- DTC B2287 is stored when there is an open or short circuit or an ECU communication malfunction between the power source control ECU and certification ECU (smart key ECU assembly).
- DTC B278C is stored when LIN communication between the certification ECU (smart key ECU assembly) and power source control ECU stops for 10 seconds or more.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|
| B2287 | There is an open or short circuit or an ECU communication malfunction between the power source control ECU and certification ECU (smart key ECU assembly). | Certification ECU (smart key ECU assembly) Power source control ECU Harness or connector |
| B278C | No communication between the certification ECU (smart key ECU assembly) and power source control ECU for 10 seconds or more. | Certification ECU (smart key ECU assembly) Power source control ECU Harness or connector |
Scheme 44
Scheme 44: WIRING DIAGRAM
- DTC B2287 is stored when there is an open or short circuit or an ECU communication malfunction between the power source control ECU and certification ECU (smart key ECU assembly).
- DTC B278C is stored when LIN communication between the certification ECU (smart key ECU assembly) and power source control ECU stops for 10 seconds or more.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|
| B2287 | There is an open or short circuit or an ECU communication malfunction between the power source control ECU and certification ECU (smart key ECU assembly). | Certification ECU (smart key ECU assembly) Power source control ECU Harness or connector |
| B278C | No communication between the certification ECU (smart key ECU assembly) and power source control ECU for 10 seconds or more. | Certification ECU (smart key ECU assembly) Power source control ECU Harness or connector |
This DTC is stored when LIN communication between the power window regulator motor assembly LH and main body ECU (multiplex network body ECU) stops for 10 seconds or more.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|
| B2321 | No communication between the power window regulator motor assembly LH and main body ECU for 10 seconds or more. | Power window regulator motor assembly LH Main body ECU (multiplex network body ECU) Instrument panel junction block assembly Harness or connector |
Scheme 45
Scheme 45: WIRING DIAGRAM
This DTC is stored when LIN communication between the power window regulator motor assembly LH and main body ECU (multiplex network body ECU) stops for 10 seconds or more.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|
| B2321 | No communication between the power window regulator motor assembly LH and main body ECU for 10 seconds or more. | Power window regulator motor assembly LH Main body ECU (multiplex network body ECU) Instrument panel junction block assembly Harness or connector |
The main body ECU (multiplex network body ECU) intermittently monitors the LIN communication bus between the components related to the doors and sliding roof drive gear sub-assembly (sliding roof ECU)*. DTC B2325 is stored when a malfunction in the LIN communication bus between the components related to the doors and sliding roof drive gear sub-assembly (sliding roof ECU)* is detected consecutively 3 times.
- *: w/ Sliding Roof System
| DTC Code | DTC Detection Condition | Trouble Area |
|---|
| B2325 | The main body ECU (multiplex network body ECU) detects a malfunction in the LIN communication bus between components related to the doors and sliding roof drive gear sub-assembly (sliding roof ECU)* consecutively 3 times. | Sliding roof drive gear sub-assembly (sliding roof ECU)* Power window regulator motor assembly LH Main body ECU (multiplex network body ECU) Instrument panel junction block assembly Harness or connector |
- *: w/ Sliding Roof System
Scheme 46
Scheme 46: WIRING DIAGRAM
The main body ECU (multiplex network body ECU) intermittently monitors the LIN communication bus between the components related to the doors and sliding roof drive gear sub-assembly (sliding roof ECU)*. DTC B2325 is stored when a malfunction in the LIN communication bus between the components related to the doors and sliding roof drive gear sub-assembly (sliding roof ECU)* is detected consecutively 3 times.
- *: w/ Sliding Roof System
| DTC Code | DTC Detection Condition | Trouble Area |
|---|
| B2325 | The main body ECU (multiplex network body ECU) detects a malfunction in the LIN communication bus between components related to the doors and sliding roof drive gear sub-assembly (sliding roof ECU)* consecutively 3 times. | Sliding roof drive gear sub-assembly (sliding roof ECU)* Power window regulator motor assembly LH Main body ECU (multiplex network body ECU) Instrument panel junction block assembly Harness or connector |
- *: w/ Sliding Roof System
The certification ECU (smart key ECU assembly) intermittently monitors the LIN communication bus between the components related to certification. DTC B2785 is stored when a malfunction in the LIN communication bus between the components related to certification is detected continuously 3 times.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|
| B2785 | The certification ECU (smart key ECU assembly) detects a malfunction in the LIN communication bus between components related to certification continuously 3 times. | Certification ECU (smart key ECU assembly) Power source control ECU ID code box (immobiliser code ECU) Steering lock actuator assembly (steering lock ECU) Harness or connector |
Scheme 47
Scheme 47: WIRING DIAGRAM
The certification ECU (smart key ECU assembly) intermittently monitors the LIN communication bus between the components related to certification. DTC B2785 is stored when a malfunction in the LIN communication bus between the components related to certification is detected continuously 3 times.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|
| B2785 | The certification ECU (smart key ECU assembly) detects a malfunction in the LIN communication bus between components related to certification continuously 3 times. | Certification ECU (smart key ECU assembly) Power source control ECU ID code box (immobiliser code ECU) Steering lock actuator assembly (steering lock ECU) Harness or connector |
This DTC is stored when LIN communication between the certification ECU (smart key ECU assembly) and steering lock actuator assembly (steering lock ECU) stops for 10 seconds or more.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|
| B2786 | LIN communication between the certification ECU (smart key ECU assembly) and steering lock ECU stops for 10 seconds or more. | Steering lock actuator assembly (steering lock ECU) Certification ECU (smart key ECU assembly) Harness or connector |
Scheme 48
Scheme 48: WIRING DIAGRAM
This DTC is stored when LIN communication between the certification ECU (smart key ECU assembly) and steering lock actuator assembly (steering lock ECU) stops for 10 seconds or more.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|
| B2786 | LIN communication between the certification ECU (smart key ECU assembly) and steering lock ECU stops for 10 seconds or more. | Steering lock actuator assembly (steering lock ECU) Certification ECU (smart key ECU assembly) Harness or connector |
This DTC is stored when LIN communication between the certification ECU (smart key ECU assembly) and ID code box (immobiliser code ECU) stops for 10 seconds or more.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|
| B2789 | No communication between the certification ECU (smart key ECU assembly) and ID code box (immobiliser code ECU) for 10 seconds or more. | ID code box (immobiliser code ECU) Certification ECU (smart key ECU assembly) Harness or connector |
Scheme 49
Scheme 49: WIRING DIAGRAM
This DTC is stored when LIN communication between the certification ECU (smart key ECU assembly) and ID code box (immobiliser code ECU) stops for 10 seconds or more.
| DTC Code | DTC Detection Condition | Trouble Area |
|---|
| B2789 | No communication between the certification ECU (smart key ECU assembly) and ID code box (immobiliser code ECU) for 10 seconds or more. | ID code box (immobiliser code ECU) Certification ECU (smart key ECU assembly) Harness or connector |
