Wiring diagram: Warning systems — Chime circuit Scion tC I facelift
All systems — 28 systems
- Air conditioning
- Anti-lock brakes
- Anti-theft
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Engine performance 2.5l
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster
- Interior lights 2
- Power distribution
- Power door locks
- Power mirrors
- Power top/sunroof
- Power windows 2
- Radio
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission
- Trunk, tailgate, fuel door
- Warning systems 2
- Wiper/washer
Components on these wiring diagrams 19
Click a component to highlight it on every diagram it appears on.
