ENGINE COMPARTMENT JUNCTION & RELAY BLOCKS
Note. For engine compartment fusible link and relay block locations (Scheme 1) For description of electrical power distribution (Scheme 2)
Component Locations
- Fusible link block is located at left side of engine compartment. For identification of components (Scheme 3) For identification of protected circuits, see «Engine Compartment Fusible Link Block Protected Circuits»(ref-351549-S01964444282009122200000). For wiring diagrams of circuits, see POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS article.
- Engine compartment relay block and relay block no.2 are located at left of engine compartment. For identification of components (Scheme 3) For identification of protected circuits, see «Engine Compartment Relay Block Protected Circuits»(ref-351549-S04841187132009122200000) or «Engine Compartment Relay Block No. 2 Protected Circuits»(ref-351549-S01964444282009122200000). For wiring diagrams of circuits, see POWER DISTRIBUTION in SYSTEM WIRING DIAGRAMS article.
| Fuse | System | |
|---|---|---|
| 60A | ABS | VSC |
| 60A | MAIN | Charging |
| Combination Meter | ||
| Electronically Controlled Transmission and A/T Indicator | ||
| Engine Control | ||
| SRS | ||
| Starting and Ignition | ||
| VSC | ||
| 120A | ALT | Charging |
| VSC | ||
Engine Compartment Fusible Link Block Protected Circuits
Scheme 1
Scheme 2
Scheme 3
| Fuse | System | |
|---|---|---|
| 7.5A | A/C2 | Air Conditioning |
| 10A | H-LP LH/H-LP LO LH | Headlight |
| Wireless Door Lock Control | ||
| 10A | H-LP RH/H-LP LO RH | Headlight |
| Wireless Door Lock Control | ||
| 15A | AM2 | Charging |
| Combination Meter | ||
| Electronically Controlled Transmission and A/T Indicator | ||
| Engine Control | ||
| SRS | ||
| Starting and Ignition | ||
| VSC | ||
| 15A | DOME | Audio System |
| Combination Meter | ||
| Door Lock Control | ||
| Engine Control | ||
| Headlight | ||
| Interior Light | ||
| Key Reminder and Seat Belt Warning | ||
| Light Reminder | ||
| SRS | ||
| Taillight and Illumination | ||
| VSC | ||
| Wireless Door Lock Control | ||
| 15A | EFI | Electronically Controlled Transmission and A/T Indicator |
| Engine Control | ||
| 15A | HORN | Horn |
| Wireless Door Lock Control | ||
| 30A | RDI | Radiator Fan and Condenser Fan |
| 30A | ST | Starting and Ignition |
| 40A | ABS NO.2 | VSC |
| 50A | HTR SUB1 | PTC Heater |
Engine Compartment Relay Block Protected Circuits
Scheme 4
| Fuse | System | |
|---|---|---|
| 7.5A | ST | Electronically Controlled Transmission and A/T Indicator |
| Engine Control | ||
| Starting | ||
Engine Compartment Relay Block No. 2 Protected Circuits
PASSENGER COMPARTMENT JUNCTION & RELAY BLOCKS
Note. For instrument panel junction block location (Scheme 5) For description of electrical power distribution (Scheme 2)
Component Locations
- For identification of instrument panel junction block components (Scheme 6)
- For identification of Rear Window Defogger fuse (Scheme 7)
- For identification of protected circuits, see «Instrument Panel Junction Block Protected Circuits»(ref-351549-S39749178562009122200000).
- For wiring diagrams of circuits, see POWER DISTRIBUTION in appropriate SYSTEM WIRING DIAGRAMS article.
Scheme 5
Scheme 6
Scheme 7
| Fuse | System | |
|---|---|---|
| 7.5A | A/C | Air Conditioning |
| Engine Control | ||
| PTC Heater | ||
| Two Way Flow Heater | ||
| 7.5A | ECU-B | Multiplex Communication System (CAN) |
| VSC | ||
| 7.5A | ECU-IG | ABS |
| Engine Control | ||
| Multiplex Communication System (CAN) | ||
| PTC Heater | ||
| Radiator Fan and Condenser Fan | ||
| Taillight and Illumination | ||
| Two Way Flow Heater | ||
| VSC | ||
| 7.5A | OBD | Electronically Controlled Transmission and A/T Indicator |
| Engine Control | ||
| 10A | GAUGE | ABS |
| Air Conditioning | ||
| Back-Up Light | ||
| Charging | ||
| Combination Meter | ||
| Door Lock Control | ||
| Electronically Controlled Transmission and A/T Indicator | ||
| Engine Control | ||
| Key Reminder and Seat Belt Warning | ||
| Light Reminder | ||
| Power Window | ||
| Rear Window Defogger | ||
| Shift Lock | ||
| Sliding Roof | ||
| SRS | ||
| Turn Signal and Hazard Warning Light | ||
| Two Way Flow Heater | ||
| VSC | ||
| 10A | HAZ | Turn Signal and Hazard Warning Light |
| 10A | STOP | ABS |
| Electronically Controlled Transmission and A/T Indicator | ||
| Engine Control | ||
| Shift Lock | ||
| Stop Light | ||
| VSC | ||
| 10A | TAIL | Light Reminder |
| Taillight and Illumination | ||
| 15A | ACC | Audio System |
| Cigarette Lighter | ||
| Remote Control Mirror | ||
| 25A | DEF | Rear Window Defogger |
| 25A | D/L | Door Lock Control |
| 25A | WIPER | Front Wiper and Washer |
| Rear Wiper and Washer | ||
| 30A | POWER | Power Window |
| Sliding Roof | ||
| 40A | HTR | Air Conditioning |
| Two Way Flow Heater | ||
Instrument Panel Relay/Junction Block Protected Circuits
