1. REMOVE FRONT FENDER LINER LH Remove the 3 screws. Partially remove the fender liner. HINT: It is not necessary to fully remove the fender liner. Partially remove it so that the bumper cover can be removed later.
2. REMOVE FRONT FENDER LINER RH HINT: Use the same procedures described for the LH side.
3. REMOVE FRONT BUMPER COVER Remove the 3 screws and 2 bolts. Using a clip remover, remove the clip labeled A, 2 clips labeled B, and 2 radiator protectors. Apply protective tape under the front fender. Using a screwdriver, detach the 6 claws labeled A and 2 claws labeled B, and remove the bumper cover. HINT: Tape the screwdriver tip before use.
4. REMOVE FRONT BUMPER ENERGY ABSORBER
5. REMOVE FRONT BUMPER REINFORCEMENT SUB-ASSEMBLY Remove the 6 nuts and reinforcement.
6. REMOVE FRONT BUMPER SIDE SUPPORT LH Remove the screw and bolt. Using a screwdriver, detach the 2 clips, and remove the side support. HINT: Tape the screwdriver tip before use.
7. REMOVE FRONT BUMPER SIDE SUPPORT RH HINT: Use the same procedures described for the LH side.

Scheme 63

1. REMOVE HOOD TO FRONT END PANEL SEAL Using a clip remover, detach the 8 clips and remove the panel seal.
2. REMOVE FRONT BUMPER REINFORCEMENT Using a clip remover, remover the 2 clips and reinforcement from the bumper cover.
3. REMOVE RADIATOR GRILLE LOWER
4. REMOVE FRONT BUMPER HOLE COVER
5. REMOVE FRONT BUMPER GUARD COVER LH Using a screwdriver, detach the 3 claws and remove the cover. HINT: Tape the screwdriver tip before use.
6. REMOVE FRONT BUMPER GUARD COVER RH HINT: Use the same procedures described for the LH side.
