Lighting: Removal & Installation Scion tC I рестайлинг

REMOVAL

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 10

Scheme 11

1. REMOVE FRONT FENDER LINER LH (See «REMOVAL»(ref-296261-S18214386042008082200000) )
2. REMOVE FRONT FENDER LINER RH (See «REMOVAL»(ref-296261-S18214386042008082200000) )
3. REMOVE FRONT BUMPER COVER (See «REMOVAL»(ref-296261-S18214386042008082200000) )
4. REMOVE HEADLIGHT ASSEMBLY Remove the bolt and 2 screws. Disengage the claw. Disconnect the connectors. Disengage the clamp and remove the headlight assembly.

INSTALLATION

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

1. INSTALL HEADLIGHT ASSEMBLY Engage the clamp. Connect the connectors. Engage the claw and install the headlight assembly with the bolt and 2 screws. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf)
2. INSTALL FRONT BUMPER COVER (See «INSTALLATION»(ref-296261-S38101614042008082200000) )
3. INSTALL FRONT FENDER LINER LH (See «INSTALLATION»(ref-296261-S38101614042008082200000) )
4. INSTALL FRONT FENDER LINER RH (See «INSTALLATION»(ref-296261-S38101614042008082200000) )
5. VEHICLE PREPARATION FOR HEADLIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-296262-S38573387692008082200000) )
6. PREPARATION FOR HEADLIGHT AIMING (Using a headlight aim test machine) (See «ADJUSTMENT»(ref-296262-S38573387692008082200000) )
7. PREPARATION FOR HEADLIGHT AIMING (Using a screen) (See «ADJUSTMENT»(ref-296262-S38573387692008082200000) )
8. INSPECT HEADLIGHT AIMING (See «ADJUSTMENT»(ref-296262-S38573387692008082200000) )
9. ADJUST HEADLIGHT AIMING (See «ADJUSTMENT»(ref-296262-S38573387692008082200000) )

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 12

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE FRONT FENDER LINER LH (See «REMOVAL»(ref-296261-S18214386042008082200000) )
3. REMOVE FRONT FENDER LINER RH (See «REMOVAL»(ref-296261-S18214386042008082200000) )
4. REMOVE FRONT BUMPER COVER (See «REMOVAL»(ref-296261-S18214386042008082200000) )
5. REMOVE HEADLIGHT ASSEMBLY LH Remove the 2 screws and bolt and disengage the claw. Disconnect the connectors and remove the headlight.

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 13

1. INSTALL HEADLIGHT ASSEMBLY LH Connect the connectors, and install the LH headlight assembly. Install the 2 screws and bolt and attach the claw.
2. INSTALL FRONT BUMPER COVER (See «INSTALLATION»(ref-296261-S38101614042008082200000) )
3. INSTALL FRONT FENDER LINER RH (See «INSTALLATION»(ref-296261-S38101614042008082200000) )
4. INSTALL FRONT FENDER LINER LH (See «INSTALLATION»(ref-296261-S38101614042008082200000) )
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
6. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
7. VEHICLE PREPARATION FOR HEADLIGHT AIM ADJUSTMENT (See «ADJUSTMENT»(ref-296262-S24457888902008082200000) )
8. PREPARATION FOR HEADLIGHT AIMING (Using a tester) (See «ADJUSTMENT»(ref-296262-S24457888902008082200000) )
9. PREPARATION FOR HEADLIGHT AIMING (Using a screen) (See «ADJUSTMENT»(ref-296262-S24457888902008082200000) )
10. INSPECT HEADLIGHT AIMING (See «ADJUSTMENT»(ref-296262-S24457888902008082200000) )
11. ADJUST HEADLIGHT AIMING (See «ADJUSTMENT»(ref-296262-S24457888902008082200000) )

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 14

Scheme 15

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE OUTER REAR VIEW MIRROR ASSEMBLY LH (See «REMOVAL»(ref-296266-S06883513312008082200000) )
3. REMOVE SIDE TURN SIGNAL LIGHT LENS LH Detach the 4 claws and remove the cover. Remove the 2 screws. Disconnect the connector and remove the side turn signal light lens LH.

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 16

1. INSTALL SIDE TURN SIGNAL LIGHT LENS LH Connect the connector and install the side turn signal light lens LH. Install the 2 screws. Attach the 4 claws and install the cover.
2. INSTALL OUTER REAR VIEW MIRROR ASSEMBLY LH (See «INSTALLATION»(ref-296266-S16962442282008082200000) )
3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
4. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 17

Scheme 18

1. INSPECT REAR COMBINATION LIGHT ASSEMBLY Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition 2-6 Light control switch is in TAIL position 10 to 14 V 3-6 Shift R position 10 to 14 V 4-6 Turn signal switch is in LH (RH) position Alternating between 0 to 9 V (60 to 120 times per minute) 5-6 Brake pedal is depressed 10 to 14 V

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 19

Scheme 20

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE REAR BUMPER COVER (See «REMOVAL»(ref-296261-S09918894932008082200000) )
3. REMOVE REAR FLOOR SERVICE HOLE COVER Detach the claw and remove the rear floor service hole cover.
4. REMOVE REAR COMBINATION LIGHT ASSEMBLY LH Disconnect the connector. Remove the 3 nuts. Remove the pin, and then remove the rear combination light.

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

1. INSTALL REAR COMBINATION LIGHT ASSEMBLY LH Install the pin, and then install the rear combination light assembly LH. Install the 3 nuts. Connect the connector.
2. INSTALL REAR FLOOR SERVICE HOLE COVER Install the rear floor service hole cover.
3. INSTALL REAR BUMPER COVER (See «INSTALLATION»(ref-296261-S15535827732008082200000) )
4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
5. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 21

Scheme 22

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 23

Scheme 24

Scheme 25

1. REMOVE REAR BUMPER COVER (See «REMOVAL»(ref-296261-S09918894932008082200000) )
2. REMOVE REAR COMBINATION LIGHT SERVICE COVER Disengage the claw. Disengage the 2 guides and remove the rear combination light service cover.
3. REMOVE REAR COMBINATION LIGHT ASSEMBLY Disconnect the connector and disengage the clamp. Remove the 3 nuts. Disengage the guide and pin, and remove the rear combination light assembly.

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 26

1. INSTALL REAR COMBINATION LIGHT ASSEMBLY Engage the guide and pin. Install the rear combination light assembly with 3 the nuts. Torque: 4.9 N*m (50 kgf*cm, 43 in.*lbf) Connect the connector and engage the clamp.
2. INSTALL REAR COMBINATION LIGHT SERVICE COVER Engage the 2 guides. Engage the claw and install the rear combination light service cover.
3. INSTALL REAR BUMPER COVER (See «INSTALLATION»(ref-296261-S15535827732008082200000) )

Scheme 27

Scheme 28

1. INSPECT LICENSE PLATE LIGHT ASSEMBLY Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition 1-2 Light control switch is in TAIL position 10 to 14 V

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE BACK DOOR GARNISH CENTER (See «DISASSEMBLY»(ref-296249-S37793972602008082200000) )
3. REMOVE BACK DOOR SIDE GARNISH LH (See «DISASSEMBLY»(ref-296249-S37793972602008082200000) )
4. REMOVE BACK DOOR SIDE GARNISH RH (See «DISASSEMBLY»(ref-296249-S37793972602008082200000) )
5. REMOVE BACK DOOR GARNISH SUB - ASSEMBLY OUTSIDE (See «REMOVAL»(ref-296261-S37484917372008082200000) )

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

1. INSTALL LICENSE PLATE LIGHT ASSEMBLY Attach the 2 claws and install the license plate light assembly. Connect the connector.
2. INSTALL BACK DOOR GARNISH SUB-ASSEMBLY OUTSIDE
3. INSTALL BACK DOOR SIDE GARNISH RH (See «REASSEMBLY»(ref-296249-S36814679302008082200000) )
4. INSTALL BACK DOOR SIDE GARNISH LH (See «REASSEMBLY»(ref-296249-S36814679302008082200000) )
5. INSTALL BACK DOOR GARNISH CENTER (See «REASSEMBLY»(ref-296249-S36814679302008082200000) )
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
7. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 29

Scheme 30

1. INSPECT CENTER STOP LIGHT ASSEMBLY Measure the voltage according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition 1-2 Brake pedal is depressed 10 to 14 V

Scheme 31

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE BACK DOOR GARNISH CENTER (See «DISASSEMBLY»(ref-296249-S37793972602008082200000) )
3. REMOVE BACK DOOR SIDE GARNISH LH (See «DISASSEMBLY»(ref-296249-S37793972602008082200000) )
4. REMOVE BACK DOOR SIDE GARNISH RH (See «DISASSEMBLY»(ref-296249-S37793972602008082200000) )
5. REMOVE BACK DOOR GARNISH SUB-ASSEMBLY OUTSIDE
6. REMOVE CENTER STOP LIGHT ASSEMBLY Disconnect the connector. Remove the 4 nuts and detach the 2 claws, and then remove the center stop light.

Scheme 32

1. INSTALL CENTER STOP LIGHT ASSEMBLY Install the 4 nuts and attach the 2 claws, and then install the center stop light. Connect the connector.
2. INSTALL BACK DOOR GARNISH SUB-ASSEMBLY OUTSIDE
3. INSTALL BACK DOOR SIDE GARNISH RH (See «REASSEMBLY»(ref-296249-S36814679302008082200000) )
4. INSTALL BACK DOOR SIDE GARNISH LH (See «REASSEMBLY»(ref-296249-S36814679302008082200000) )
5. INSTALL BACK DOOR GARNISH CENTER (See «REASSEMBLY»(ref-296249-S36814679302008082200000) )
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
7. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 33

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE MAP LIGHT ASSEMBLY (See «REMOVAL»(ref-296260-S33289777892008082200000) )

Scheme 34

1. INSPECT MAP LIGHT ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition 3-4 3-8 Switch is OFF 10 kohms or higher Connect the battery positive (+) lead to terminal 3 and the battery negative (-) lead to terminal 8, and then check that the light comes on when the switch is in the DOOR position. OK: Light comes on. Connect the battery positive (+) lead to terminal 3 and the battery negative (-) lead to terminal 4, and then check that the light comes on when the switch is in the ON position. OK: Light comes on.

1. INSTALL MAP LIGHT ASSEMBLY (See «INSTALLATION»(ref-296260-S06943096042008082200000) )
2. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
3. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 35

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE NO. 1 ROOM LIGHT ASSEMBLY (See «REMOVAL»(ref-296260-S33289777892008082200000) )

Scheme 36

1. INSPECT NO. 1 ROOM LIGHT ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition 1-2 1-3 Switch is OFF 10 kohms or higher Connect the battery positive (+) lead to terminal 1 and the battery negative (-) lead to terminal 2, nd then check that the light comes on when the switch is in the DOOR position. OK: Light comes on. Connect the battery positive (+) lead to terminal 1 and the battery negative (-) lead to terminal 3, and then check that the light comes on when the switch is in the ON position. OK: Light comes on.

1. INSTALL NO. 1 ROOM LIGHT ASSEMBLY (See «INSTALLATION»(ref-296260-S06943096042008082200000) )
2. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
3. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 37

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE NO. 2 ROOM LIGHT ASSEMBLY (See «REMOVAL»(ref-296260-S33289777892008082200000) )

Scheme 38

1. INSPECT NO. 2 ROOM LIGHT ASSEMBLY Connect the battery positive (+) lead to terminal 2 and the battery negative (-) lead to terminal 1, and then check that the light comes on when the switch is in the ON position. OK: Light comes on.

1. INSTALL NO. 2 ROOM LIGHT ASSEMBLY (See «INSTALLATION»(ref-296260-S06943096042008082200000) )
2. DISCONNECT CABLE TO NEGATIVE BATTERY TERMINAL
3. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 39

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE STEERING COLUMN COVER (See «REMOVAL»(ref-296250-S21065635202008082200000) )
3. REMOVE TRANSPONDER KEY AMPLIFIER (See «REMOVAL»(ref-296250-S21065635202008082200000) )

Scheme 40

1. INSPECT TRANSPONDER KEY AMPLIFIER Inspect the ignition key cylinder light operation. Connect the battery positive (+) lead to terminal 2 and the battery negative (-) lead to terminal 6, and then check that the light comes on. OK: Light comes on.

1. INSTALL STEERING COLUMN COVER (See «REMOVAL»(ref-296250-S21065635202008082200000) )
2. INSTALL TRANSPONDER KEY AMPLIFIER (See «INSTALLATION»(ref-296250-S20001670472008082200000) )
3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
4. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 41

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (See «REMOVAL»(ref-296255-S31055646022008082200000) )
3. REMOVE INDICATOR LIGHT ASSEMBLY Disconnect the connector. Detach the clip and remove the light.

Scheme 42

1. INSPECT INDICATOR LIGHT Inspect front console illumination. Connect the battery positive (+) lead to terminal 1 and the battery negative (-) lead to terminal 2, and then check that the light comes on. OK: Light comes on.

1. INSTALL INDICATOR LIGHT ASSEMBLY Attach the clip and install the light. Connect the connector.
2. INSTALL INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (See «INSTALLATION»(ref-296255-S20800291322008082200000) )
3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
4. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 43

Scheme 44

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE STEERING COLUMN COVER (See «REMOVAL»(ref-296250-S21065635202008082200000) )
3. REMOVE HEADLIGHT DIMMER SWITCH ASSEMBLY Disconnect the connector. Detach the claw and remove the headlight dimmer switch. NOTE: Do not push the claw strongly, otherwise it will be damaged.

Scheme 45

1. INSPECT HEADLIGHT DIMMER SWITCH ASSEMBLY Inspect the light control switch. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition 13-16 14-16 OFF 10 kohms or higher 14-16 TAIL Below 1 ohms 13-16 14-16 HEAD Below 1 ohms Inspect the headlight dimmer switch. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition 8-16 7-8 FLASH Below 1 ohms 16-17 LOW BEAM Below 1 ohms 7-16 HIGH BEAM Below 1 ohms Inspect the turn signal switch. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition 1-2 Left turn Below 1 ohms 1-2 2-3 Neutral 10 kohms or higher 2-3 Right turn Below 1 ohms

1. INSTALL HEADLIGHT DIMMER SWITCH ASSEMBLY Attach the claw and install the headlight dimmer switch assembly. Connect the connector.
2. INSTALL STEERING COLUMN COVER
3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
4. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 46

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (for Manual Transaxle) (See «REMOVAL»(ref-296246-S03403041552008082200000) )
3. REMOVE UPPER CONSOLE PANEL (See «REMOVAL»(ref-296246-S03403041552008082200000) )
4. REMOVE INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (See «REMOVAL»(ref-296255-S31055646022008082200000) )

Scheme 47

1. INSPECT AIR CONDITIONING AMPLIFIER ASSEMBLY (HAZARD WARNING SWITCH) Inspect the hazard warning switch resistance. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition 9-25 OFF 10 kohms or higher 9-25 ON Below 1 ohms Connect the positive lead (+) from the battery to terminal 25 and the negative (-) lead to terminal 9, and then check that the light comes on. OK: Light comes on.

1. INSTALL INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (See «INSTALLATION»(ref-296255-S20800291322008082200000) )
2. INSTALL UPPER CONSOLE PANEL (See «REMOVAL»(ref-296246-S03403041552008082200000) )
3. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (See «REMOVAL»(ref-296246-S03403041552008082200000) )
4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
5. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 48

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE STOP LIGHT SWITCH ASSEMBLY (See «REMOVAL»(ref-296238-S13826596632008082200000) )

Scheme 49

1. INSPECT STOP LIGHT SWITCH ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition 1-2 Switch pin free Below 1 ohms 3-4 Switch pin free 10 kohms or higher 1-2 Switch pin pushed in 10 kohms or higher 3-4 Switch pin pushed in Below 1 ohms

1. INSTALL STOP LIGHT SWITCH ASSEMBLY (See «INSTALLATION»(ref-296238-S26366575992008082200000) )
2. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
3. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 50

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE BACK-UP LIGHT SWITCH ASSEMBLY (See «REMOVAL»(ref-296239-S38963198292008082200000) )

Scheme 51

1. INSPECT BACK-UP LIGHT SWITCH ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition 1-2 OFF 10 kohms or higher 1-2 ON Below 1 ohms

1. INSTALL BACK-UP LIGHT SWITCH ASSEMBLY (See «INSTALLATION»(ref-296239-S15798474202008082200000) )
2. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
3. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 52

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY Remove the bolt and switch. Disconnect the connector.

1. INSTALL FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY Connect the connector. Install the switch with the bolt.
2. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
3. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 53

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE BACK DOOR GARNISH CENTER (See «DISASSEMBLY»(ref-296249-S37793972602008082200000) )
3. REMOVE BACK DOOR SIDE GARNISH LH (See «DISASSEMBLY»(ref-296249-S37793972602008082200000) )
4. REMOVE BACK DOOR SIDE GARNISH RH (See «DISASSEMBLY»(ref-296249-S37793972602008082200000) )
5. REMOVE BACK DOOR TRIM BOARD ASSEMBLY (See «DISASSEMBLY»(ref-296249-S37793972602008082200000) )
6. REMOVE BACK DOOR LOCK ASSEMBLY (See «DISASSEMBLY»(ref-296249-S37793972602008082200000) )

Scheme 54

1. INSPECT BACK DOOR LOCK ASSEMBLY Inspect the back door courtesy light switch. Measure the resistance according to the value(s) in the table below. Standard STANDARD REFERENCE Tester Connection Condition Specified Condition 1-2 Back door is closed 10 ohms or higher 1-2 Back door is opened Below 1 ohms

1. INSTALL BACK DOOR LOCK ASSEMBLY (See «REASSEMBLY»(ref-296249-S36814679302008082200000) )
2. INSTALL BACK DOOR TRIM BOARD ASSEMBLY (See «REASSEMBLY»(ref-296249-S36814679302008082200000) )
3. INSTALL BACK DOOR SIDE GARNISH RH (See «REASSEMBLY»(ref-296249-S36814679302008082200000) )
4. INSTALL BACK DOOR SIDE GARNISH LH (See «REASSEMBLY»(ref-296249-S36814679302008082200000) )
5. INSTALL BACK DOOR GARNISH CENTER (See «REASSEMBLY»(ref-296249-S36814679302008082200000) )
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
7. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 55

Scheme 56

Scheme 57

1. INSPECT TURN SIGNAL FLASHER OPERATION Inspect the power source circuit and ground circuit Remove the turn signal flasher relay from the instrument panel junction block assembly. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition 1 - Body ground Ignition switch OFF Below 1 V 1 - Body ground Ignition switch ON 10 to 14 V 4 - Body ground Always 10 to 14 V Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition 7 - Body ground Always Below 1 ohms Inspect the output operation signal. Install the turn signal flasher relay to the instrument panel junction block assembly. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition 1A-27 - Body ground Hazard warning switch OFF 0 V 1A-27 - Body ground Hazard warning switch ON Alternating between 0 to 9 V (60 to 120 times per minute) 1A-27 - Body ground Turn signal switch (left turn) OFF 0V 1A-27 - Body ground Turn signal switch (left turn) ON Alternating between 0 to 9 V (60 to 120 times per minute) 1A-28 - Body ground Hazard warning switch OFF 0V 1A-28 - Body ground Hazard warning switch ON Alternating between 0 to 9 V (60 to 120 times per minute) 1A-28 - Body ground Turn signal switch (right turn) OFF 0 V 1A-28 - Body ground Turn signal switch (right turn) ON Alternating between 0 to 9 V (60 to 120 times per minute) 1B-14 - Body ground Hazard warning signal OFF 0V 1B-14 - Body ground Hazard warning signal ON 0 above 9 V (60 to 120 times per minute) 1B-14 - Body ground Turn signal switch (left turn) OFF 0 V 1B-14 - Body ground Turn signal switch (left turn) ON Alternating between 0 to 9 V (60 to 120 times per minute) 1B-31 - Body ground Hazard warning signal OFF 0 V 1B-31 - Body ground Hazard warning signal ON Alternating between 0 to 9 V (60 to 120 times per minute) 1B-31 - Body ground Turn signal switch (right turn) OFF 0 V 1B-31 - Body ground Turn signal switch (right turn) ON 0 above 9 V (60 to 120 times per minute) 1S-11 - Body ground Turn signal switch (left turn) OFF Above 9 V 1S-11 - Body ground Turn signal switch (left turn) ON 0 V 1S-12 - Body ground Turn signal switch (right turn) OFF Above 9 V 1S-12 - Body ground Turn signal switch (right turn) ON 0 V 1S-13- Body ground Hazard warning signal OFF 0V 1S-13 - Body ground Hazard warning signal ON Alternating between 0 to 9 V (60 to 120 times per minute) 1S-13 - Body ground Turn signal switch (left turn) OFF 0V 1A-13 - Body ground Turn signal switch (left turn) ON Alternating between 0 to 9 V (60 to 120 times per minute) 1S-16 - Body ground Hazard warning switch OFF 0 V 1S-16 - Body ground Hazard warning switch ON Alternating between 0 to 9 V (60 to 120 times per minute) 1S-16 - Body ground Turn signal switch (right turn) OFF 0 V 1S-16 - Body ground Turn signal switch (right turn) ON Alternating between 0 to 9 V (60 to 120 times per minute) 1S-17 - Body ground Hazard switch OFF Above 9 V 1S-17 - Body ground Hazard switch ON 0 V

Scheme 58

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE HEADLIGHT RELAY (Marking: H-LP)

Scheme 59

1. INSPECT HEADLIGHT RELAY Measure the resistance according to the value(s) in the table below. RESISTANCE REFERENCE Tester Connection Standard resistance 3-5 10 kohms or higher 3-5 Below 1 ohms (When battery voltage is applied to terminals 1-2)

1. INSTALL HEADLIGHT RELAY
2. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
3. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 60

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE TAILLIGHT (Marking: T-LP)

Scheme 61

1. INSPECT TAILLIGHT RELAY Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Specified Condition 3-5 10 kohms or higher 3-5 Below 1 ohms (when battery voltage is applied to terminals 1-2)

1. INSTALL TAILLIGHT RELAY
2. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
3. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
