PROBLEM SYMPTOMS TABLE
HINT
Proceed to the troubleshooting for each circuit in the table (Scheme 16)
Scheme 16
Scheme 17
Scheme 18
Scheme 19
- DTCS FOR SUPPLEMENTAL RESTRAINT SYSTEM If a trouble code is displayed during the DTC check, check the circuit listed for the code in the table (Scheme 18)(Proceed to the Service Category listed for that circuit). HINT: When the SRS warning light remains on and the DTC output is the normal system code, a voltage source drop is likely to occur. This malfunction is not stored in memory by the airbag sensor assy center. If the power source voltage returns to normal, the SRS warning light will automatically go off. When 2 or more codes are indicated, the code with the lower number appears first. If a code is not listed on the display chart, the airbag sensor assy center may have failed. In the case of any malfunction concerning an open circuit, short to ground, or short to B+ due to an squib, other trouble codes may not be detected. In this case, repair the malfunction currently indicated and then perform malfunction diagnosis again. Mark in the check mode column: "O": DTC is corresponding to the check mode. "-": DTC is not corresponding to the check mode. When DTC B1650/32 is detected as a result of troubleshooting for the Supplemental Restraint System, perform troubleshooting for the occupant classification system (Scheme 18)
| DTC | Description |
|---|---|
| DTC B1000/31 | AIRBAG SENSOR ASSY CENTER MALFUNCTION |
| DTC B1610/13 | FRONT AIRBAG SENSOR (RH) CIRCUIT MALFUNCTION |
| DTC B1615/14 | FRONT AIRBAG SENSOR (LH) CIRCUIT MALFUNCTION |
| DTC B1620/21 | SIDE AIRBAG SENSOR ASSEMBLY (D SEAT SIDE) MALFUNCTION |
| DTC B1625/22 | SIDE AIRBAG SENSOR ASSEMBLY (P SEAT SIDE) MALFUNCTION |
| DTC B1630/23 | CURTAIN SHIELD AIRBAG SENSOR (D SEAT SIDE) MALFUNCTION |
| DTC B1635/24 | CURTAIN SHIELD AIRBAG SENSOR (P SEAT SIDE) MALFUNCTION |
| DTC B1653/35 | SEAT POSITION SENSOR ASSEMBLY MALFUNCTION |
| DTC B1655/37 | SEAT BELT BUCKLE SWITCH (D SEAT SIDE) MALFUNCTION |
| DTC B1800/51, B1801/51, B1802/51, B1803/51 | SHORT/OPEN IN D SQUIB CIRCUIT & SHORT IN D SQUIB CIRCUIT (TO GROUND/TO B+) |
| DTC B1805/52, B1806/52, B1807/52, B1808/52 | SHORT/OPEN IN P SQUIB CIRCUIT & SHORT IN P SQUIB CIRCUIT (TO GROUND TO B+) |
| DTC B1810/53, B1811/53, B1812/53, B1813/53 | SHORT/OPEN IN D SQUIB (DUAL STAGE - 2ND STEP) CIRCUIT & SHORT IN D SQUIB (DUAL STAGE - 2ND STEP) CIRCUIT (TO GROUND/TO B+) |
| DTC B1815/54, B1816/54, B1817/54, B1818/54 | SHORT/OPEN IN P SQUIB (DUAL STAGE - 2ND STEP) CIRCUIT & SHORT IN P SQUIB (DUAL STAGE - 2ND STEP) CIRCUIT (TO GROUND/TO B+) |
| DTC B1820/55, B1821/55, B1822/55, B1823/55 | SHORT/OPEN IN SIDE SQUIB (D SEAT SIDE) CIRCUIT & SHORT IN SIDE SQUIB (D SEAT SIDE) CIRCUIT (TO GROUND/TO B+) |
| DTC B1825/56, B1826/56, B1827/56, B1828/56 | SHORT/OPEN IN SIDE SQUIB (P SEAT SIDE) CIRCUIT & SHORT IN SIDE SQUIB (P SEAT SIDE) CIRCUIT (TO GROUND/TO B+) |
| DTC B1830/57, B1832/57, B1831/57, B1833/57 | SHORT/OPEN IN CURTAIN SHIELD AIRBAG (D SEAT SIDE) SQUIB CIRCUIT & SHORT IN CURTAIN SHIELD AIRBAG (D SEAT SIDE) SQUIB CIRCUIT (TO GROUND/TO B+) |
| DTC B1835/58, B1836/58, B1837/58, B1838/58 | SHORT/OPEN IN CURTAIN SHIELD AIRBAG (P SEAT SIDE) SQUIB CIRCUIT & SHORT IN CURTAIN SHIELD AIRBAG (P SEAT SIDE) SQUIB CIRCUIT (TO GROUND/TO B+) |
| DTC B1860/64, B1861/64, B1862/64, B1863/64 | SHORT/OPEN IN KNEE AIRBAG SQUIB CIRCUIT & SHORT IN KNEE AIRBAG SQUIB CIRCUIT (TO GROUND/TO B+) |
| DTC B1900/73, B1901/73, B1902/73, B1903/73 | SHORT/OPEN IN P/T SQUIB (D SEAT SIDE) CIRCUIT & SHORT IN P/T SQUIB (D SEAT SIDE) CIRCUIT (TO GROUND/TO B+) |
| DTC B1905/74, B1906/74, B1907/74, B1908/74 | SHORT/OPEN IN P/T SQUIB (P SEAT SIDE) CIRCUIT & SHORT IN P/T SQUIB (P SEAT SIDE) CIRCUIT (TO GROUND/TO B+) |
